Rax Eco 180-190

Rax Eco 180-190 White 3000/4000K Ra>80 DALI-2

Article code
212588
EAN
7021982125881
Back to articlelist

Overview

Wattage
7,5W/16W
Efficacy
113/124/110/121lm/W
Lumen
850lm/930lm/1760lm/1940lm
IP Class
IP20
Colour temperature
3000/4000K
Colour rendering (Ra)
Ra>80
Lifetime
50,000 L80/B20>
Mounting
Indoor
    5 years Warranty
  • indoor
  • dipswitch
  • cctsw
  • ip20
  • klasse_2
  • ce

Tools

Downloads

Specification sheet 212588 Mounting instruction Rax Eco 180-190 Dali_User Manual EPD NEPD-8255-7927_Rax-Eco-180-190-Dali CE Declaration Rax Eco 180-190 Relux file (rolf) 7021982125881_Rax_Eco_180-190_White_1760lm_3000K_Ra80_DALI Relux file (rolf) 7021982125881_Rax_Eco_180-190_White_1940lm_4000K_Ra80_DALI Relux file (rolf) 7021982125881_Rax_Eco_180-190_White_850lm_3000K_Ra80_DALI Relux file (rolf) 7021982125881_Rax_Eco_180-190_White_930lm_4000K_Ra80_DALI Eulumdat file (ldt) 7021982125881_Rax Eco 180-190 White 1760lm 3000K Ra80 DALI Eulumdat file (ldt) 7021982125881_Rax Eco 180-190 White 1940lm 4000K Ra80 DALI Eulumdat file (ldt) 7021982125881_Rax Eco 180-190 White 850lm 3000K Ra80 DALI Eulumdat file (ldt) 7021982125881_Rax Eco 180-190 White 930lm 4000K Ra80 DALI Dialux file (uld) 7021982125881_Rax Eco 180-190 White 1760lm 3000K Ra80 DALI Dialux file (uld) 7021982125881_Rax Eco 180-190 White 1940lm 4000K Ra80 DALI Dialux file (uld) 7021982125881_Rax Eco 180-190 White 850lm 3000K Ra80 DALI Dialux file (uld) 7021982125881_Rax Eco 180-190 White 930lm 4000K Ra80 DALI Revit file - Generic Rax ECO 180 -190 Dali - generic Revit file - Ceiling Based Rax Eco 180-190 Dali- ceiling based

How to specify

Text copied to clipboard

Rax Eco 180-190 White 3000/4000K Ra>80 DALI-2, Article code: 212588, EAN: 7021982125881, IP20, Electrical: Wattage: 7,5W/16W, Voltage: 220-240V, Frequency (Hz): 50/60Hz, Max. luminaires per circuit breaker: B10: 90, B16: 150, C10: 90, C16: 150, Light technic: Type of light source: LED, Luminous flux: 850lm/930lm/1760lm/1940lm, Efficacy: 113/124/110/121lm/W, Colour temperature: 3000/4000K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L80/B20>50,000, Light distribution: Direct, Optic: Reflector, Beam angle: 95°, Photobiological safety: RG 1, Control/Dimming: Type: DALI-2, Protection: Luminaire class: Class II, IP Class: IP20, Materials and finish: Housing: Polycarbonat (PC), Colour: White (RAL 9003), Optics: Acrylic (PMMA), Mounting/Connection: Mounting: Indoor, Connection: 5 pol Linect / screwless terminal block, Dimensions: Height (mm) H: 93, Diameter (mm) D: 210, Cut-out (mm): 180, Ceiling void depth (mm): 93, Weight (kg) gross/net: 1 / 0.78, Packaging: Packaging dimensions (mm): 230 x 222 x 110

Electrical

Wattage
7,5W/16W
Voltage
220-240V
Frequency (Hz)
50/60Hz
Max. luminaires per circuit breaker
B10: 90, B16: 150, C10: 90, C16: 150

Light technic

Type of light source
LED
Luminous flux
850lm/930lm/1760lm/1940lm
Efficacy
113/124/110/121lm/W
Colour temperature
3000/4000K
Colour rendering (Ra)
Ra>80
MacAdams factor
SDCM: 3
Lifetime
L80/B20>50,000
Light distribution
Direct
Optic
Reflector
Beam angle
95°
Photobiological safety
RG 1

Control/Dimming

Type
DALI-2

Protection

Luminaire class
Class II
IP Class
IP20

Materials and finish

Housing
Polycarbonat (PC)
Colour
White (RAL 9003)
Optics
Acrylic (PMMA)

Mounting/Connection

Mounting
Indoor
Connection
5 pol Linect / screwless terminal block

Dimensions

Height (mm) H
93
Diameter (mm) D
210
Cut-out (mm)
180
Ceiling void depth (mm)
93
Weight (kg) gross/net
1 / 0.78

Packaging

Packaging dimensions (mm)
230 x 222 x 110
