Rax Eco 200

Rax ECO 200 White 3000/4000K Ra>80 DALI-2

Article code
212587
EAN
7021982125874
Back to articlelist

Overview

Wattage
12W/20W
Efficacy
117/123/111/118lm/W
Lumen
1400lm/1480lm/2210lm/2360lm
IP Class
IP20
Colour temperature
3000/4000K
Colour rendering (Ra)
Ra>80
Lifetime
50,000 L80/B20>
Mounting
Indoor
    5 years Warranty
  • indoor
  • cctsw
  • ip20
  • klasse_2
  • ce

Tools

Downloads

Specification sheet 212587 Revit file - Generic Rax ECO 200 Dali - generic Revit file - Ceiling Based Rax ECO 200 Dali - ceiling based

See more

Mounting instruction Rax Eco 200 Dali_User Manual Eulumdat file (ldt) 7021982125874_Rax Eco 200 White 1400lm 3000K Ra80 DALI Eulumdat file (ldt) 7021982125874_Rax Eco 200 White 1480lm 4000K Ra80 DALI Eulumdat file (ldt) 7021982125874_Rax Eco 200 White 2210lm 3000K Ra80 DALI Eulumdat file (ldt) 7021982125874_Rax Eco 200 White 2360lm 4000K Ra80 DALI Dialux file (uld) 7021982125874_Rax Eco 200 White 1400lm 3000K Ra80 DALI Dialux file (uld) 7021982125874_Rax Eco 200 White 1480lm 4000K Ra80 DALI Dialux file (uld) 7021982125874_Rax Eco 200 White 2210lm 3000K Ra80 DALI Dialux file (uld) 7021982125874_Rax Eco 200 White 2360lm 4000K Ra80 DALI Relux file (rolf) 7021982125874_Rax_Eco_200_White_1400lm_3000K_Ra80_DALI Relux file (rolf) 7021982125874_Rax_Eco_200_White_1480lm_4000K_Ra80_DALI Relux file (rolf) 7021982125874_Rax_Eco_200_White_2210lm_3000K_Ra80_DALI Relux file (rolf) 7021982125874_Rax_Eco_200_White_2360lm_4000K_Ra80_DALI EPD NEPD-8254-7928_Rax-Eco-200-Dali CE Declaration Rax Eco 200

How to specify

Text copied to clipboard

Rax ECO 200 White 3000/4000K Ra>80 DALI-2, Article code: 212587, EAN: 7021982125874, IP20, Electrical: Wattage: 12W/20W, Voltage: 220-240V, Frequency (Hz): 50/60Hz, Max. luminaires per circuit breaker: B10: 40, B16: 60, C10: 40, C16: 60, Light technic: Type of light source: LED, Luminous flux: 1400lm/1480lm/2210lm/2360lm, Efficacy: 117/123/111/118lm/W, Colour temperature: 3000/4000K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L80/B20>50,000, Light distribution: Direct, Optic: Reflector, Beam angle: 95°, Control/Dimming: Type: DALI-2, Protection: Luminaire class: Class II, IP Class: IP20, Materials and finish: Housing: Polycarbonat (PC), Colour: White (RAL 9003), Optics: Acrylic (PMMA), Mounting/Connection: Mounting: Indoor, Connection: 5 pol Linect / screwless terminal block, Dimensions: Height (mm) H: 93, Diameter (mm) D: 216, Cut-out (mm): 200, Ceiling void depth (mm): 93, Weight (kg) gross/net: 1.03 / 0.87, Packaging: Packaging dimensions (mm): 240 x 222 x 120

Electrical

Wattage
12W/20W
Voltage
220-240V
Frequency (Hz)
50/60Hz
Max. luminaires per circuit breaker
B10: 40, B16: 60, C10: 40, C16: 60

Light technic

Type of light source
LED
Luminous flux
1400lm/1480lm/2210lm/2360lm
Efficacy
117/123/111/118lm/W
Colour temperature
3000/4000K
Colour rendering (Ra)
Ra>80
MacAdams factor
SDCM: 3
Lifetime
L80/B20>50,000
Light distribution
Direct
Optic
Reflector
Beam angle
95°

Control/Dimming

Type
DALI-2

Protection

Luminaire class
Class II
IP Class
IP20

Materials and finish

Housing
Polycarbonat (PC)
Colour
White (RAL 9003)
Optics
Acrylic (PMMA)

Mounting/Connection

Mounting
Indoor
Connection
5 pol Linect / screwless terminal block

Dimensions

Height (mm) H
93
Diameter (mm) D
216
Cut-out (mm)
200
Ceiling void depth (mm)
93
Weight (kg) gross/net
1.03 / 0.87

Packaging

Packaging dimensions (mm)
240 x 222 x 120
