Artes Midi

Artes Midi White 1560lm 2700K Ra>80 Trailing edge

Article code
641709
EAN
7021986417098
Back to articlelist

Overview

Efficacy
49 lm/W
Lumen
1560lm
IP Class
IP65
Colour temperature
2700K
Colour rendering (Ra)
Ra>80
Lifetime
100,000 L70/B10>
Mounting
Wall, Indoor / Outdoor
    5 years corrosion warranty 5 years Warranty
  • indoor
  • outdoor
  • dipswitch
  • ik10
  • ip65
  • klasse_2
  • ce

Tools

Downloads

Specification sheet 641709 Eulumdat file (ldt) 7021986417098_Artes Midi White 1560lm 2700K Ra80 Trailing edge dimming Dialux file (uld) 7021986417098_Artes Midi White 1560lm 2700K Ra80 Trailing edge dimming

See more

Relux file (rolf) 7021986417098_Artes_Midi_White_1560lm_2700K_Ra_80_Trailing_edge_dimming EPD NEPD-8037-7718_Artes-Midi Revit file - Generic Artes Midi - generic Revit file - Face Based Artes Midi - face based Mounting instruction Artes Midi_User Manual CE Declaration Artes Midi

How to specify

Text copied to clipboard

Artes Midi White 1560lm 2700K Ra>80 Trailing edge, Article code: 641709, EAN: 7021986417098, IP65, IK10, Electrical: System wattage: 32W, Voltage: 220-240V, Max. luminaires per circuit breaker: B10: 19, B16: 30, C10: 31, C16: 51, Light technic: Type of light source: LED, Luminous flux: 1560lm, Efficacy: 49 lm/W, Colour temperature: 2700K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L70/B10>100,000, Lifetime: L80/B50>80,000, Optic: Lens, Beam angle: 60°, Visible flicker (PstLM): 0.07, Stroboscopic flicker (SVM): 0.07, Photobiological safety: RG 1, ULOR (<1%): Yes, for direct only, Control/Dimming: Type: Trailing edge, Protection: Luminaire class: Class II, IK Class: IK10, IP Class: IP65, Energy and approvals: Contains light source of energy class: E, Breeam: Fulfils Hea 01 for flicker free lighting, BVB: Yes, Materials and finish: Housing: Aluminium, Colour: White (RAL 9003), Optics: UV-stabilized polycarbonate, Mounting/Connection: Mounting: Wall, Indoor / Outdoor, Connection: Screwless terminal block, Dimensions: Length (mm) L: 205, Width (mm) W: 205, Height (mm) H: 125, Weight (kg) gross/net: 2.63 / 2.385, Packaging: Packaging dimensions (mm): 220 x 212 x 137

Electrical

System wattage
32W
Voltage
220-240V
Max. luminaires per circuit breaker
B10: 19, B16: 30, C10: 31, C16: 51

Light technic

Type of light source
LED
Luminous flux
1560lm
Efficacy
49 lm/W
Colour temperature
2700K
Colour rendering (Ra)
Ra>80
MacAdams factor
SDCM: 3
Lifetime
L70/B10>100,000
Lifetime
L80/B50>80,000
Optic
Lens
Beam angle
60°
Visible flicker (PstLM)
0.07
Stroboscopic flicker (SVM)
0.07
Photobiological safety
RG 1
ULOR (<1%)
Yes, for direct only

Control/Dimming

Type
Trailing edge

Protection

Luminaire class
Class II
IK Class
IK10
IP Class
IP65

Energy and approvals

Contains light source of energy class
E
Breeam
Fulfils Hea 01 for flicker free lighting
BVB
Yes

Materials and finish

Housing
Aluminium
Colour
White (RAL 9003)
Optics
UV-stabilized polycarbonate

Mounting/Connection

Mounting
Wall, Indoor / Outdoor
Connection
Screwless terminal block

Dimensions

Length (mm) L
205
Width (mm) W
205
Height (mm) H
125
Weight (kg) gross/net
2.63 / 2.385

Packaging

Packaging dimensions (mm)
220 x 212 x 137
