Sense 300x300

Sense 300X300 White 2480lm 4000K Ra>80 Trailing edge

Article code
212273
EAN
7021982122736
Back to articlelist

Overview

Efficacy
124 lm/W
Lumen
2480lm
IP Class
IP40/IP20
Colour temperature
4000K
Colour rendering (Ra)
Ra>80
Lifetime
100,000 L80/B20>
Mounting
Recessed, Indoor
    5 years Warranty
  • indoor
  • ik08
  • ip20ip40
  • klasse_2
  • selv
  • ce
  • enec

Tools

Downloads

Specification sheet 212273 Eulumdat file (ldt) 7021982122736_Sense 300x300 Matt White 2350lm 4000K Ra80 Trailing edge dimming Dialux file (uld) 7021982122736_Sense 300x300 Matt White 2350lm 4000K Ra80 Trailing edge dimming

See more

Relux file (rolf) 7021982122736_Sense_300X300_White_2350lm_4000K_Ra_80_Trailing_edge_dimming EPD NEPD-11679-11608_Sense-300X300 Revit file - Generic Sense300x300 - Generic Revit file - Ceiling Based Sense300x300 - ceiling based Mounting instruction Sense 300x300 Phase cut User manual CE Declaration Sense 300x300 ENEC Certificate Sense 300x300

How to specify

Text copied to clipboard

Sense 300X300 White 2480lm 4000K Ra>80 Trailing edge, Article code: 212273, EAN: 7021982122736, IP40/IP20, IK08, Electrical: System wattage: 20W, Voltage: 220-240V, Max. luminaires per circuit breaker: B10: 19, B16: 30, C10: 31, C16: 51, Light technic: Type of light source: LED, Luminous flux: 2480lm, Efficacy: 124 lm/W, Colour temperature: 4000K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L80/B20>100,000, Lifetime: L90>50,000, Light distribution: Direct, Optic: Opal, Photobiological safety: RG 0, Control/Dimming: Type: Trailing edge, Protection: Luminaire class: Class II SELV, IK Class: IK08, IP Class: IP40/IP20, Energy and approvals: Contains light source of energy class: D, Breeam: Fulfils Hea 01 for flicker free lighting, Materials and finish: Housing: Aluminium, Colour: White smooth (Ral 9016 gloss 30), Optics: Acrylic (PMMA), Mounting/Connection: Mounting: Recessed, Indoor, Dimensions: Length (mm) L: 300, Width (mm) W: 300, Height (mm) H: 25, Cut-out (mm): 285, Ceiling void depth (mm): 25, Weight (kg) gross/net: 3.6 / 3, Packaging: Packaging dimensions (mm): 345 x 310 x 65

Electrical

System wattage
20W
Voltage
220-240V
Max. luminaires per circuit breaker
B10: 19, B16: 30, C10: 31, C16: 51

Light technic

Type of light source
LED
Luminous flux
2480lm
Efficacy
124 lm/W
Colour temperature
4000K
Colour rendering (Ra)
Ra>80
MacAdams factor
SDCM: 3
Lifetime
L80/B20>100,000
Lifetime
L90>50,000
Light distribution
Direct
Optic
Opal
Photobiological safety
RG 0

Control/Dimming

Type
Trailing edge

Protection

Luminaire class
Class II SELV
IK Class
IK08
IP Class
IP40/IP20

Energy and approvals

Contains light source of energy class
D
Breeam
Fulfils Hea 01 for flicker free lighting

Materials and finish

Housing
Aluminium
Colour
White smooth (Ral 9016 gloss 30)
Optics
Acrylic (PMMA)

Mounting/Connection

Mounting
Recessed, Indoor

Dimensions

Length (mm) L
300
Width (mm) W
300
Height (mm) H
25
Cut-out (mm)
285
Ceiling void depth (mm)
25
Weight (kg) gross/net
3.6 / 3

Packaging

Packaging dimensions (mm)
345 x 310 x 65
