Sense Basic 300x600

Sense Basic 300x600 White 2220lm 4000K Ra>80 On/Off

Article code
212147
EAN
7021982121470
Back to articlelist

Overview

Efficacy
111 lm/W
Lumen
2220lm
IP Class
IP20
Colour temperature
4000K
Colour rendering (Ra)
Ra>80
Lifetime
100,000 L80/B20>
Mounting
Indoor
  • indoor
  • dipswitch
  • ik06
  • ip20
  • klasse_2

Tools

Downloads

Specification sheet 212147 Revit file - Generic Sense Basic 300x600 - generic Revit file - Face Based Sense Basic-300x600 - face based

See more

Eulumdat file (ldt) 7021982121470_Sense Basic 300x600 White 2220lm 4000K Ra80 OnOff Dialux file (uld) 7021982121470_Sense Basic 300x600 White 2220lm 4000K Ra80 OnOff Relux file (rolf) 7021982121470_Sense_Basic_300x600_White_2220lm_4000K_Ra_80_On_Off EPD Sense-Basic-300x600 Mounting instruction Sense Basic 300x600_User Manual CE Declaration Sense Basic ENEC Certificate Sense Basic 300x600

How to specify

Text copied to clipboard

Sense Basic 300x600 White 2220lm 4000K Ra>80 On/Off, Article code: 212147, EAN: 7021982121470, IP20, IK06, Electrical: System wattage: 20W, Max. luminaires per circuit breaker: B10: 38, B16: 60, C10: 57, C16: 91, Light technic: Type of light source: LED, Luminous flux: 2220lm, Efficacy: 111 lm/W, Colour temperature: 4000K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L80/B20>100,000, Light distribution: Direct, Optic: Opalprism, UGR: UGR<22, Visible flicker (PstLM): 0.17, Stroboscopic flicker (SVM): 0.02, Control/Dimming: Type: On/Off, Protection: Luminaire class: Class II, IK Class: IK06, IP Class: IP20, Energy and approvals: Contains light source of energy class: C, Breeam: Fulfils Hea 01 for flicker free lighting, Materials and finish: Housing: Steel, Colour: White smooth (Ral 9016 gloss 30), Optics: Acrylic (PMMA), Mounting/Connection: Mounting: Indoor, Module: 300x600, Connection: 3 pol Linect / screwless terminal block, Dimensions: Length (mm) L: 595, Width (mm) W: 295, Height (mm) H: 36, Depth (D): 36, Weight (kg) gross/net: 2.105 / 1.3, Packaging: Packaging dimensions (mm): 690 x 360 x 90

Electrical

System wattage
20W
Max. luminaires per circuit breaker
B10: 38, B16: 60, C10: 57, C16: 91

Light technic

Type of light source
LED
Luminous flux
2220lm
Efficacy
111 lm/W
Colour temperature
4000K
Colour rendering (Ra)
Ra>80
MacAdams factor
SDCM: 3
Lifetime
L80/B20>100,000
Light distribution
Direct
Optic
Opalprism
UGR
UGR<22
Visible flicker (PstLM)
0.17
Stroboscopic flicker (SVM)
0.02

Control/Dimming

Type
On/Off

Protection

Luminaire class
Class II
IK Class
IK06
IP Class
IP20

Energy and approvals

Contains light source of energy class
C
Breeam
Fulfils Hea 01 for flicker free lighting

Materials and finish

Housing
Steel
Colour
White smooth (Ral 9016 gloss 30)
Optics
Acrylic (PMMA)

Mounting/Connection

Mounting
Indoor
Module
300x600
Connection
3 pol Linect / screwless terminal block

Dimensions

Length (mm) L
595
Width (mm) W
295
Height (mm) H
36
Depth (D)
36
Weight (kg) gross/net
2.105 / 1.3

Packaging

Packaging dimensions (mm)
690 x 360 x 90
