Sense Eco Opalprism

Sense ECO 600x600 White Opalprism 4000K Ra>80

Article code
212223
EAN
7021982122231
Back to articlelist

Overview

IP Class
IP40/IP20
Colour temperature
4000K
Colour rendering (Ra)
Ra>80
Lifetime
50,000 L80/B20>
Mounting
Recessed, Indoor
    5 years Warranty
  • indoor
  • dipswitch
  • ik10
  • ip20ip40
  • klasse_3
  • ce
  • enec

Tools

Downloads

Specification sheet 212223 Revit file - Generic Sense ECO opalprism 600x600 - generic Revit file - Face Based Sense Eco 600x600 Opalprism - face based

See more

Eulumdat file (ldt) 7021982122231_Sense Eco Opalprism 600x600 White 27W LED 4000K Ra80 700mA-42898 Dialux file (uld) 7021982122231_Sense Eco Opalprism 600x600 White 27W LED 4000K Ra80 700mA Relux file (rolf) 7021982122231_Sense_Eco_600x600_White_Opalprism_3130lm_4000K_Ra80_@700mA EPD NEPD-8757-8415_Sense-ECO-Opalprism Mounting instruction Sense Eco 600x600_User manual CE Declaration Sense Eco Opalprism ENEC Certificate Sense Eco Opalprism

How to specify

Text copied to clipboard

Sense ECO 600x600 White Opalprism 4000K Ra>80, Article code: 212223, EAN: 7021982122231, IP40/IP20, IK10, Light technic: Type of light source: LED, Colour temperature: 4000K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L80/B20>50,000, Lifetime: L90>50,000, Light distribution: Direct, Optic: Opalprism, Beam angle: 110°, Photobiological safety: RG 0, Protection: Luminaire class: Class III, IK Class: IK10, IP Class: IP40/IP20, Energy and approvals: Contains light source of energy class: D, BVB: Yes, Sunda Hus: C-, Materials and finish: Housing: Aluminium, Colour: White smooth (Ral 9016 gloss 30), Optics: Acrylic (PMMA), Mounting/Connection: Mounting: Recessed, Indoor, Module: 600x600 Exposed T-carrier 15/24mm, Connection: Quick connector, Dimensions: Length (mm) L: 595, Width (mm) W: 595, Height (mm) H: 10, Weight (kg) gross/net: 3.05 / 3, Packaging: Packaging dimensions (mm): 628 x 630 x 33

Light technic

Type of light source
LED
Colour temperature
4000K
Colour rendering (Ra)
Ra>80
MacAdams factor
SDCM: 3
Lifetime
L80/B20>50,000
Lifetime
L90>50,000
Light distribution
Direct
Optic
Opalprism
Beam angle
110°
Photobiological safety
RG 0

Protection

Luminaire class
Class III
IK Class
IK10
IP Class
IP40/IP20

Energy and approvals

Contains light source of energy class
D
BVB
Yes
Sunda Hus
C-

Materials and finish

Housing
Aluminium
Colour
White smooth (Ral 9016 gloss 30)
Optics
Acrylic (PMMA)

Mounting/Connection

Mounting
Recessed, Indoor
Module
600x600 Exposed T-carrier 15/24mm
Connection
Quick connector

Dimensions

Length (mm) L
595
Width (mm) W
595
Height (mm) H
10
Weight (kg) gross/net
3.05 / 3

Packaging

Packaging dimensions (mm)
628 x 630 x 33
