Sense Pro 600x600

Sense Pro 600x600 White 4990lm 3000K Ra>80 Trailing edge

Article code
212670+820494
EAN
7021982126703+7021988204948
Back to articlelist

Overview

Efficacy
131 lm/W
Lumen
4990lm
IP Class
IP40/IP20
Colour temperature
3000K
Colour rendering (Ra)
Ra>80
Lifetime
100,000 L80/B20>
Mounting
Recessed, Indoor
    5 years Warranty
  • indoor
  • ik10
  • ip20ip40
  • klasse_3
  • ce
  • enec

Tools

Downloads

Specification sheet 212670+820494 Mounting instruction Sense 5000lm Driver Kit Phase Dim_user manual Eulumdat file (ldt) 70219821267037021988204948_Sense Pro 600x600 White 4990lm 3000K Ra80 Trailing edge dimming

See more

Dialux file (uld) 70219821267037021988204948_Sense Pro 600x600 White 4990lm 3000K Ra80 Trailing edge dimming Relux file (rolf) 70219821267037021988204948_Sense_Pro_600x600_White_4990lm_3000K_Ra_80_Trailing_edge_dimming CE Declaration Sense Pro

How to specify

Text copied to clipboard

Sense Pro 600x600 White 4990lm 3000K Ra>80 Trailing edge, Article code: 212670+820494, EAN: 7021982126703+7021988204948, IP40/IP20, IK10, Electrical: System wattage: 38W, Voltage: 220-240V, Max. luminaires per circuit breaker: B10: 18, B16: 30, C10: 31, C16: 51, Light technic: Type of light source: LED, Luminous flux: 4990lm, Efficacy: 131 lm/W, Colour temperature: 3000K, Colour rendering (Ra): Ra>80, Lifetime: L80/B20>100,000, Lifetime: L90>50,000, Light distribution: Direct, Optic: Opalprism, Beam angle: 110°, Control/Dimming: Type: Trailing edge, Protection: Luminaire class: Class III, IK Class: IK10, IP Class: IP40/IP20, Energy and approvals: Breeam: Fulfils Hea 01 for flicker free lighting, Materials and finish: Housing: Aluminium, Colour: White, Optics: Acrylic (PMMA), Mounting/Connection: Mounting: Recessed, Indoor, Module: Exposed T-carrier 15/24mm, Connection: Quick connector, Dimensions: Length (mm) L: 597, Width (mm) W: 597, Height (mm) H: 11, Weight (kg) gross/net: 2.761

Electrical

System wattage
38W
Voltage
220-240V
Max. luminaires per circuit breaker
B10: 18, B16: 30, C10: 31, C16: 51

Light technic

Type of light source
LED
Luminous flux
4990lm
Efficacy
131 lm/W
Colour temperature
3000K
Colour rendering (Ra)
Ra>80
Lifetime
L80/B20>100,000
Lifetime
L90>50,000
Light distribution
Direct
Optic
Opalprism
Beam angle
110°

Control/Dimming

Type
Trailing edge

Protection

Luminaire class
Class III
IK Class
IK10
IP Class
IP40/IP20

Energy and approvals

Breeam
Fulfils Hea 01 for flicker free lighting

Materials and finish

Housing
Aluminium
Colour
White
Optics
Acrylic (PMMA)

Mounting/Connection

Mounting
Recessed, Indoor
Module
Exposed T-carrier 15/24mm
Connection
Quick connector

Dimensions

Length (mm) L
597
Width (mm) W
597
Height (mm) H
11
Weight (kg) gross/net
2.761
