Sense Pro 600x600

Sense Pro 600x600 White 3000K Ra>90

Article code
212672
EAN
7021982126727
Replaces
212156
Back to articlelist

Overview

IP Class
IP44/IP20
Colour temperature
3000K
Colour rendering (Ra)
Ra>90
Lifetime
100,000 L80/B20>
  • ik06
  • ip44ip20
  • klasse_3
  • ce
  • enec

Tools

Downloads

Specification sheet 212672 Mounting instruction Sense CRI90 IP44_User Manual EPD NEPD-5721-5015_Sense-Pro-600x600 CE Declaration Sense Pro Relux file (rolf) 7021982126727_Sense_Pro_600x600_White_2870lm_3000K_Ra_90_@700mA Relux file (rolf) 7021982126727_Sense_Pro_600x600_White_3640lm_3000K_Ra_90_@900mA Relux file (rolf) 7021982126727_Sense_Pro_600x600_White_4240lm_3000K_Ra_90_@1050mA Eulumdat file (ldt) 7021982126727_Sense Pro 600x600 White 2870lm 3000K Ra90 @700mA Eulumdat file (ldt) 7021982126727_Sense Pro 600x600 White 3640lm 3000K Ra90 @900mA Eulumdat file (ldt) 7021982126727_Sense Pro 600x600 White 4240lm 3000K Ra90 @1050mA Dialux file (uld) 7021982126727_Sense Pro 600x600 White 2870lm 3000K Ra90 @700mA Dialux file (uld) 7021982126727_Sense Pro 600x600 White 3640lm 3000K Ra90 @900mA Dialux file (uld) 7021982126727_Sense Pro 600x600 White 4240lm 3000K Ra90 @1050mA Revit file - Generic Sense Pro 600x600 - generic Revit file - Face Based Sense Pro 600x600 - face based

How to specify

Text copied to clipboard

Sense Pro 600x600 White 3000K Ra>90, Article code: 212672, EAN: 7021982126727, IP44/IP20, IK06, Light technic: Type of light source: LED, Colour temperature: 3000K, Colour rendering (Ra): Ra>90, MacAdams factor: SDCM: 3, Lifetime: L80/B20>100,000, Lifetime: L90>50,000, Light distribution: Direct, Optic: Opalprism, Beam angle: 110°, Photobiological safety: RG 0, Protection: Luminaire class: Class III, IK Class: IK06, IP Class: IP44/IP20, Energy and approvals: Contains light source of energy class: D, Materials and finish: Housing: Aluminium, Colour: White smooth (Ral 9016 gloss 30), Optics: Acrylic (PMMA), Mounting/Connection: Module: Exposed T-carrier 15/24mm, Connection: Quick connector, Dimensions: Length (mm) L: 597, Width (mm) W: 597, Height (mm) H: 11, Weight (kg) gross/net: 4.055 / 3.557, Packaging: Packaging dimensions (mm): 628 x 630 x 33

Light technic

Type of light source
LED
Colour temperature
3000K
Colour rendering (Ra)
Ra>90
MacAdams factor
SDCM: 3
Lifetime
L80/B20>100,000
Lifetime
L90>50,000
Light distribution
Direct
Optic
Opalprism
Beam angle
110°
Photobiological safety
RG 0

Protection

Luminaire class
Class III
IK Class
IK06
IP Class
IP44/IP20

Energy and approvals

Contains light source of energy class
D

Materials and finish

Housing
Aluminium
Colour
White smooth (Ral 9016 gloss 30)
Optics
Acrylic (PMMA)

Mounting/Connection

Module
Exposed T-carrier 15/24mm
Connection
Quick connector

Dimensions

Length (mm) L
597
Width (mm) W
597
Height (mm) H
11
Weight (kg) gross/net
4.055 / 3.557

Packaging

Packaging dimensions (mm)
628 x 630 x 33
