Sense Round TW

Sense TW White 495 3770lm (@6500K) 2700-6500K Ra>80 TW LEDDim

Article code
212305
EAN
7021982123054
Back to articlelist

Overview

Efficacy
105 lm/W
Lumen
3770lm (@6500K)
IP Class
IP40/IP20
Colour temperature
2700-6500K
Colour rendering (Ra)
Ra>80
Lifetime
50,000 L80/B20>
Mounting
Recessed, Indoor
    5 years Warranty
  • indoor
  • ik08
  • ip20ip40
  • klasse_2
  • selv
  • tw
  • ce
  • enec

Tools

Downloads

Specification sheet 212305 Mounting instruction Sense 495 TW LEDDim User manual EPD NEPD-12392-12448_Sense-495-TW CE Declaration Sense Round TW Relux file (rolf) 7021982123054_Sense_TW_White_495_3770lm_(@6500K)_2700-6500K_Ra_80_Trailing_edge_dimming_Tunable_White_LEDDim Eulumdat file (ldt) 7021982123054_Sense 495 TW Matt White 36W LED 2700-6500K Ra80 LEDDim-41538 Dialux file (uld) 7021982123054_Sense 495 TW Matt White 36W LED 2700-6500K Ra80 LEDDim Revit file - Generic Sense 495 - Generic Revit file - Ceiling Based Sense 495 - ceiling based ENEC Certificate Sense Round TW

How to specify

Text copied to clipboard

Sense TW White 495 3770lm (@6500K) 2700-6500K Ra>80 TW LEDDim, Article code: 212305, EAN: 7021982123054, IP40/IP20, IK08, Electrical: System wattage: 36W, Voltage: 220-240V, Max. luminaires per circuit breaker: B10: 21, B16: 33, C10: 21, C16: 33, Light technic: Type of light source: LED, Luminous flux: 3770lm (@6500K), Efficacy: 105 lm/W, Colour temperature: 2700-6500K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L80/B20>50,000, Lifetime: L90>50,000, Light distribution: Direct, Optic: Opal, Photobiological safety: RG 0, Control/Dimming: Type: TW LEDDim, Protection: Luminaire class: Class II SELV, IK Class: IK08, IP Class: IP40/IP20, Energy and approvals: Contains light source of energy class: E, Breeam: Fulfils Hea 01 for flicker free lighting, Materials and finish: Housing: Aluminium, Colour: White smooth (Ral 9016 gloss 30), Optics: Acrylic (PMMA), Mounting/Connection: Mounting: Recessed, Indoor, Connection: 3 pol Linect / screwless terminal block, Dimensions: Height (mm) H: 29, Diameter (mm) D: 495, Cut-out (mm): 475, Ceiling void depth (mm): 29, Weight (kg) gross/net: 3.1 / 2.6, Packaging: Packaging dimensions (mm): 505 x 505 x 65

Electrical

System wattage
36W
Voltage
220-240V
Max. luminaires per circuit breaker
B10: 21, B16: 33, C10: 21, C16: 33

Light technic

Type of light source
LED
Luminous flux
3770lm (@6500K)
Efficacy
105 lm/W
Colour temperature
2700-6500K
Colour rendering (Ra)
Ra>80
MacAdams factor
SDCM: 3
Lifetime
L80/B20>50,000
Lifetime
L90>50,000
Light distribution
Direct
Optic
Opal
Photobiological safety
RG 0

Control/Dimming

Type
TW LEDDim

Protection

Luminaire class
Class II SELV
IK Class
IK08
IP Class
IP40/IP20

Energy and approvals

Contains light source of energy class
E
Breeam
Fulfils Hea 01 for flicker free lighting

Materials and finish

Housing
Aluminium
Colour
White smooth (Ral 9016 gloss 30)
Optics
Acrylic (PMMA)

Mounting/Connection

Mounting
Recessed, Indoor
Connection
3 pol Linect / screwless terminal block

Dimensions

Height (mm) H
29
Diameter (mm) D
495
Cut-out (mm)
475
Ceiling void depth (mm)
29
Weight (kg) gross/net
3.1 / 2.6

Packaging

Packaging dimensions (mm)
505 x 505 x 65
