Ecoline D/I

How to specify

EcoLine 1200 White D/I 4650lm 3000K Ra>80 DALI-2, Article code: 212804, EAN: 7021982128042, IP20, Electrical: System wattage: 32W, Voltage: 220-240V, Frequency (Hz): 50/60Hz, Max. luminaires per circuit breaker: B10: 13, B16: 20, C10: 21, C16: 34, Leakage current (mA): 0,07, Light technic: Type of light source: LED, Light source included: Yes, Luminous flux: 4650lm, Efficacy: 145 lm/W, Colour temperature: 3000K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L90/B10>100,000, Lifetime: L96>50,000, Light distribution: Direct/Indirect, Optic: Opalprism, UGR: UGR<16, Visible flicker (PstLM): 0,04, Stroboscopic flicker (SVM): 0, Control/Dimming: Type: DALI-2, Protection: Luminaire class: Class I, IP Class: IP20, Energy and approvals: Contains light source of energy class: B, Breeam: Fulfils Hea 01 for flicker free lighting, Materials and finish: Housing: Sheet steel, Optics: Acrylic (PMMA), Mounting/Connection: Mounting: Suspended, Indoor, Module: 1200, Wire set: 2x2m wire kit, Cable: Cable 5x0,75mm² 2,5m, Connection: Cable 5x0,75mm² 2,5m white, Dimensions: Length (mm) L: 1235, Width (mm) W: 166, Height (mm) H: 58, Weight (kg) gross/net: 5.15 / 4.65, Packaging: Packaging dimensions (mm): 1255 x 180 x 72
