Tysnes 66

Tysnes 66 1500 Grey 6720lm 3000K Ra>80 DALI-2

Article code
120072
EAN
7021981200725
Back to articlelist

Overview

Efficacy
156 lm/W
Lumen
6720lm
IP Class
IP66
Colour temperature
3000K
Colour rendering (Ra)
Ra>80
Lifetime
100,000 L80/B20>
    5 years Warranty
  • d
  • el
  • flickerfree
  • ik10
  • ip66
  • klasse_1

Tools

Downloads

Specification sheet 120072 Eulumdat file (ldt) 7021981200725_Tysnes 66 1500 Grey 6720lm 3000K Ra80 DALI-2 Dialux file (uld) 7021981200725_Tysnes 66 1500 Grey 6720lm 3000K Ra80 DALI-2

See more

Relux file (rolf) 7021981200725_Tysnes_66_1500_Grey_6720lm_3000K_Ra_80_DALI-2 Mounting instruction Tysnes 66_User Manual HACCP 4724055-240001_Test Attestation (SG Armaturen AS - Tysnes 66) CE Declaration Tysnes 66

How to specify

Text copied to clipboard

Tysnes 66 1500 Grey 6720lm 3000K Ra>80 DALI-2, Article code: 120072, EAN: 7021981200725, IP66, IK10, Electrical: System wattage: 43W, Voltage: 220-240V, Max. luminaires per circuit breaker: B10: 12, B16: 20, C10: 21, C16: 34, Light technic: Type of light source: LED, Luminous flux: 6720lm, Efficacy: 156 lm/W, Colour temperature: 3000K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L80/B20>100,000, Lifetime: L90>50,000, Light distribution: Direct, Optic: Opal, Beam angle: 117°, Control/Dimming: Type: DALI-2, Protection: Luminaire class: Class I, IK Class: IK10, IP Class: IP66, Fire protection class: 850°C - 30s, Materials and finish: Housing: UV-stabilized polycarbonate, Colour: Grey, Optics: UV-stabilized polycarbonate, Mounting/Connection: Module: 1500, Connection: 5-pole screwless terminal block with 5x2,5mm2 through wiring, Dimensions: Length (mm) L: 1500, Width (mm) W: 85, Height (mm) H: 80, Weight (kg) gross/net: 1.98 / 1.78, Packaging: Packaging dimensions (mm): 1525 x 85 x 90

Electrical

System wattage
43W
Voltage
220-240V
Max. luminaires per circuit breaker
B10: 12, B16: 20, C10: 21, C16: 34

Light technic

Type of light source
LED
Luminous flux
6720lm
Efficacy
156 lm/W
Colour temperature
3000K
Colour rendering (Ra)
Ra>80
MacAdams factor
SDCM: 3
Lifetime
L80/B20>100,000
Lifetime
L90>50,000
Light distribution
Direct
Optic
Opal
Beam angle
117°

Control/Dimming

Type
DALI-2

Protection

Luminaire class
Class I
IK Class
IK10
IP Class
IP66
Fire protection class
850°C - 30s

Materials and finish

Housing
UV-stabilized polycarbonate
Colour
Grey
Optics
UV-stabilized polycarbonate

Mounting/Connection

Module
1500
Connection
5-pole screwless terminal block with 5x2,5mm2 through wiring

Dimensions

Length (mm) L
1500
Width (mm) W
85
Height (mm) H
80
Weight (kg) gross/net
1.98 / 1.78

Packaging

Packaging dimensions (mm)
1525 x 85 x 90
