Wave

Wave 600 White 2140lm 3000K Ra>80 Sensor Wireless

Article code
111277
EAN
7021981112776
=

This article is produced by order, with an expected delivery time of 3-4 weeks

Back to articlelist

Overview

Efficacy
119 lm/W
Lumen
2140lm
IP Class
IP44
Colour temperature
3000K
Colour rendering (Ra)
Ra>80
Lifetime
50,000 L70/B50>
Mounting
Surface, Indoor
  • indoor
  • dipswitch
  • ik06
  • ip44
  • klasse_1
  • ce

Tools

Downloads

Specification sheet 111277 Mounting instruction Wave 600 sensor Wireless_User Manual Eulumdat file (ldt) 7021981112776_Wave 600 White Sensor Wireless 2140lm 3000K Ra80 OnOff

See more

Dialux file (uld) 7021981112776_Wave 600 White Sensor Wireless 2140lm 3000K Ra80 OnOff Relux file (rolf) 7021981112776_Wave_600_White_Sensor_Wireless_2140lm_3000K_Ra_80_On_Off EPD NEPD-8539-8207_Wave-600-Sensor Revit file - Generic Wave 600 - generic Revit file - Ceiling Based Wave 600 - ceiling based CE Declaration Wave

How to specify

Text copied to clipboard

Wave 600 White 2140lm 3000K Ra>80 Sensor Wireless, Article code: 111277, EAN: 7021981112776, IP44, IK06, Electrical: System wattage: 18W, Voltage: 220-240V, Light technic: Type of light source: LED, Luminous flux: 2140lm, Efficacy: 119 lm/W, Colour temperature: 3000K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L70/B50>50,000, Light distribution: Direct, Optic: Opal, Beam angle: 110°, UGR: UGR<25, Photobiological safety: RG 0, Control/Dimming: Type: Sensor Wireless, Protection: Luminaire class: Class I, IK Class: IK06, IP Class: IP44, Energy and approvals: Contains light source of energy class: D, Breeam: Fulfils Hea 01 for flicker free lighting, Materials and finish: Housing: Steel, Aluminium, Colour: White (RAL 9003), Optics: Acrylic (PMMA), Mounting/Connection: Mounting: Surface, Indoor, Module: 600, Connection: Screwless terminal block, Dimensions: Length (mm) L: 620, Width (mm) W: 151, Height (mm) H: 54, Weight (kg) gross/net: 2.244 / 1.77, Packaging: Packaging dimensions (mm): 640 x 160 x 60

Electrical

System wattage
18W
Voltage
220-240V

Light technic

Type of light source
LED
Luminous flux
2140lm
Efficacy
119 lm/W
Colour temperature
3000K
Colour rendering (Ra)
Ra>80
MacAdams factor
SDCM: 3
Lifetime
L70/B50>50,000
Light distribution
Direct
Optic
Opal
Beam angle
110°
UGR
UGR<25
Photobiological safety
RG 0

Control/Dimming

Type
Sensor Wireless

Protection

Luminaire class
Class I
IK Class
IK06
IP Class
IP44

Energy and approvals

Contains light source of energy class
D
Breeam
Fulfils Hea 01 for flicker free lighting

Materials and finish

Housing
Steel, Aluminium
Colour
White (RAL 9003)
Optics
Acrylic (PMMA)

Mounting/Connection

Mounting
Surface, Indoor
Module
600
Connection
Screwless terminal block

Dimensions

Length (mm) L
620
Width (mm) W
151
Height (mm) H
54
Weight (kg) gross/net
2.244 / 1.77

Packaging

Packaging dimensions (mm)
640 x 160 x 60
