Tube Micro Trio

Tube Micro Trio Black DimToWarm 960lm 2000-2800K Ra>95 Trailing edge

Article code
320695
EAN
7021983206954
Back to articlelist

Overview

Efficacy
53 lm/W
Lumen
960lm
IP Class
IP21
Colour temperature
2000-2800K
Colour rendering (Ra)
Ra>95
Lifetime
50,000 L80/B20>
Mounting
Surface, Indoor
    5 years Warranty
  • indoor
  • dipswitch
  • dimtowarm
  • ip21
  • klasse_2
  • ce

Tools

Downloads

Specification sheet 320695 Revit file - Generic Tube Micro Trio - generic Revit file - Face Based Tube Micro Trio - face based

See more

Eulumdat file (ldt) 7021983206954_Tube Micro Trio Black 960lm 2000-2800K Ra95 Trailing edge dimming Dialux file (uld) 7021983206954_Tube Micro Trio Black 960lm 2000-2800K Ra95 Trailing edge dimming Relux file (rolf) 7021983206954_Tube_Micro_Trio_Black_960lm_2000-2800K_Ra_95_Trailing_edge_dimming EPD NEPD-11241-11188_Tube-Micro-Trio Mounting instruction Tube Micro Trio_User Manual CE Declaration Tube Micro Trio

How to specify

Text copied to clipboard

Tube Micro Trio Black DimToWarm 960lm 2000-2800K Ra>95 Trailing edge, Article code: 320695, EAN: 7021983206954, IP21, Electrical: System wattage: 18W, Voltage: 220-240V, Frequency (Hz): 50/60Hz, Max. luminaires per circuit breaker: B10: 43, B16: 69, C10: 43, C16: 69, Light technic: Type of light source: LED, Luminous flux: 960lm, Efficacy: 53 lm/W, Colour temperature: 2000-2800K, Colour rendering (Ra): Ra>95, MacAdams factor: SDCM: 2, Lifetime: L80/B20>50,000, Optic: Reflector medium, Beam angle: 40°, Control/Dimming: Type: Trailing edge, Protection: Luminaire class: Class II, IP Class: IP21, Energy and approvals: Contains light source of energy class: F, Breeam: Fulfils Hea 01 for flicker free lighting, BVB: Yes, Materials and finish: Housing: Aluminium, Colour: Black (RAL 9004), Optics: UV-stabilized polycarbonate, Mounting/Connection: Mounting: Surface, Indoor, Dimensions: Height (mm) H: 29, Diameter (mm) D: 250, Distance to flammable materials: 5mm, Weight (kg) gross/net: 1.793 / 1.504, Packaging: Packaging dimensions (mm): 255 x 260 x 110

Electrical

System wattage
18W
Voltage
220-240V
Frequency (Hz)
50/60Hz
Max. luminaires per circuit breaker
B10: 43, B16: 69, C10: 43, C16: 69

Light technic

Type of light source
LED
Luminous flux
960lm
Efficacy
53 lm/W
Colour temperature
2000-2800K
Colour rendering (Ra)
Ra>95
MacAdams factor
SDCM: 2
Lifetime
L80/B20>50,000
Optic
Reflector medium
Beam angle
40°

Control/Dimming

Type
Trailing edge

Protection

Luminaire class
Class II
IP Class
IP21

Energy and approvals

Contains light source of energy class
F
Breeam
Fulfils Hea 01 for flicker free lighting
BVB
Yes

Materials and finish

Housing
Aluminium
Colour
Black (RAL 9004)
Optics
UV-stabilized polycarbonate

Mounting/Connection

Mounting
Surface, Indoor

Dimensions

Height (mm) H
29
Diameter (mm) D
250
Distance to flammable materials
5mm
Weight (kg) gross/net
1.793 / 1.504

Packaging

Packaging dimensions (mm)
255 x 260 x 110
