Tube Mini S
Tube Mini S White 900lm 3000K Ra 98 Trailing edge
- Article code
- 320692
- EAN
- 7021983206923
Overview
- Efficacy
- 64 lm/W
- Lumen
- 900lm
- IP Class
- IP20
- Colour temperature
- 3000K
- Colour rendering (Ra)
- Ra 98
- Lifetime
- 100,000 L90/B10>
- Mounting
- Surface, Indoor
Tools
Downloads
Specification sheet
320692
pdf
(Opens in new tab)
Mounting instruction
Tube Mini S_User Manual
pdf
(Opens in new tab)
EPD
NEPD-11151-11105_Tube-Mini-S
pdf
(Opens in new tab)
CE Declaration
Tube Mini S
pdf
(Opens in new tab)
Relux file (rolf)
7021983206923_Tube_Mini_S_White_900lm_3000K_Ra_98_Trailing_edge_dimming
rolf
Eulumdat file (ldt)
7021983206923_Tube Mini S White 900lm 3000K Ra 98 Trailing edge dimming
ldt
Dialux file (uld)
7021983206923_Tube Mini S White 900lm 3000K Ra 98 Trailing edge dimming
uld
Revit file - Generic
Tube Mini S - generic
rfa
Revit file - Face Based
Tube Mini S - face based
rfa
Electrical
- System wattage
- 14W
- Voltage
- 220-240V
- Frequency (Hz)
- 50/60Hz
- Max. luminaires per circuit breaker
- B10: 43, B16: 69, C10: 43, C16: 69
Light technic
- Type of light source
- LED
- Luminous flux
- 900lm
- Efficacy
- 64 lm/W
- Colour temperature
- 3000K
- Colour rendering (Ra)
- Ra 98
- MacAdams factor
- SDCM: 2
- Lifetime
- L90/B10>100,000
- Optic
- Reflector medium
- Beam angle
- 40°
Control/Dimming
- Type
- Trailing edge
Protection
- Luminaire class
- Class II
- IP Class
- IP20
Energy and approvals
- Contains light source of energy class
- E
- Breeam
- Fulfils Hea 01 for flicker free lighting
- BVB
- Yes
Materials and finish
- Housing
- Aluminium
- Colour
- Matte white (RAL 9003)
- Optics
- UV-stabilized polycarbonate
Mounting/Connection
- Mounting
- Surface, Indoor
Dimensions
- Length (mm) L
- 59
- Width (mm) W
- 59
- Height (mm) H
- 160
- Diameter (mm) D
- 102
- Weight (kg) gross/net
- 0.708 / 0.617
Packaging
- Packaging dimensions (mm)
- 105 x 105 x 200
