Hurdal Maxi

Hurdal Maxi 1200 White 5870lm 4000K Ra>80 Trailing edge

Article code
113133
EAN
7021981131333
Back to articlelist

Overview

Efficacy
154 lm/W
Lumen
5870lm
IP Class
IP44
Colour temperature
4000K
Colour rendering (Ra)
Ra>80
Lifetime
100,000 L80/B20>
Mounting
Indoor
    5 years Warranty
  • indoor
  • dipswitch
  • flickerfree
  • ik07
  • ip44
  • klasse_1
  • ce

Tools

Downloads

Specification sheet 113133 Revit file - Generic Hurdal Maxi 1200 - generic Revit file - Face Based Hurdal Maxi 1200 - face based

See more

Eulumdat file (ldt) 7021981131333_Hurdal Maxi 1200 White 5870lm 4000K Ra80 Trailing edge Dialux file (uld) 7021981131333_Hurdal Maxi 1200 White 5870lm 4000K Ra80 Trailing edge Relux file (rolf) 7021981131333_Hurdal_Maxi_1200_White_5870lm_4000K_Ra_80_Trailing_edge Mounting instruction 250909_Hurdal Maxi_User Manual CE Declaration Hurdal Maxi

How to specify

Text copied to clipboard

Hurdal Maxi 1200 White 5870lm 4000K Ra>80 Trailing edge, Article code: 113133, EAN: 7021981131333, IP44, IK07, Electrical: System wattage: 38W, Voltage: 220-240V, Frequency (Hz): 50/60Hz, Max. luminaires per circuit breaker: B10: 19, B16: 30, C10: 31, C16: 51, Light technic: Type of light source: LED, Luminous flux: 5870lm, Efficacy: 154 lm/W, Colour temperature: 4000K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L80/B20>100,000, Lifetime: L90>50,000, Optic: Opal, UGR: UGR<25, Visible flicker (PstLM): 0,07, Stroboscopic flicker (SVM): 0,06, Control/Dimming: Type: Trailing edge, Driver: 1050mA, Protection: Luminaire class: Class I, IK Class: IK07, IP Class: IP44, Materials and finish: Housing: Steel, Optics: UV-stabilized polycarbonate, Mounting/Connection: Mounting: Indoor, Module: 1200, Connection: 3-pole screwless terminal block with 3x2,5mm² through wiring, Dimensions: Length (mm) L: 1220, Width (mm) W: 151, Height (mm) H: 75, Weight (kg) gross/net: 3.5 / 3, Packaging: Packaging dimensions (mm): 1243 x 155 x 88

Electrical

System wattage
38W
Voltage
220-240V
Frequency (Hz)
50/60Hz
Max. luminaires per circuit breaker
B10: 19, B16: 30, C10: 31, C16: 51

Light technic

Type of light source
LED
Luminous flux
5870lm
Efficacy
154 lm/W
Colour temperature
4000K
Colour rendering (Ra)
Ra>80
MacAdams factor
SDCM: 3
Lifetime
L80/B20>100,000
Lifetime
L90>50,000
Optic
Opal
UGR
UGR<25
Visible flicker (PstLM)
0,07
Stroboscopic flicker (SVM)
0,06

Control/Dimming

Type
Trailing edge
Driver
1050mA

Protection

Luminaire class
Class I
IK Class
IK07
IP Class
IP44

Materials and finish

Housing
Steel
Optics
UV-stabilized polycarbonate

Mounting/Connection

Mounting
Indoor
Module
1200
Connection
3-pole screwless terminal block with 3x2,5mm² through wiring

Dimensions

Length (mm) L
1220
Width (mm) W
151
Height (mm) H
75
Weight (kg) gross/net
3.5 / 3

Packaging

Packaging dimensions (mm)
1243 x 155 x 88
