Hurdal Connect

Hurdal Connect 1500 White 4640lm 3000K Ra>80 Connect

Article code
113128
EAN
7021981131289
Back to articlelist

Overview

Efficacy
150 lm/W
Lumen
4640lm
IP Class
IP44
Colour temperature
3000K
Colour rendering (Ra)
Ra>80
Lifetime
100,000 L80/B20>
Mounting
Surface, Indoor
    5 years Warranty
  • indoor
  • d
  • el
  • ip44
  • klasse_1
  • ce

Tools

Downloads

Specification sheet 113128 Mounting instruction Hurdal Connect_User Manuals EPD NEPD-14079-14423_Hurdal-Connect-1500 CE Declaration Hurdal Connect Relux file (rolf) 7021981131289_Hurdal_1500_White_4640lm_3000K_Ra_80_Connect Eulumdat file (ldt) 7021981131289_Hurdal 1500 White 4640lm 3000K Ra80 Connect Dialux file (uld) 7021981131289_Hurdal 1500 White 4640lm 3000K Ra80 Connect Revit file - Generic Hurdal 1500 connect - generic Revit file - Face Based Hurdal 1500 Connect - face based

How to specify

Text copied to clipboard

Hurdal Connect 1500 White 4640lm 3000K Ra>80 Connect, Article code: 113128, EAN: 7021981131289, IP44, Electrical: System wattage: 31W, Voltage: 220-240V, Max. luminaires per circuit breaker: B10: 26, B16: 42, C10: 43, C16: 71, Leakage current (mA): 0,4, Light technic: Type of light source: LED, Light source included: Yes, Luminous flux: 4640lm, Efficacy: 150 lm/W, Constant lumen output option: Yes, Colour temperature: 3000K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L80/B20>100,000, Lifetime: L90>50,000, Light distribution: Direct, Optic: Opal, Visible flicker (PstLM): <1, Stroboscopic flicker (SVM): <0,4, Photobiological safety: RG 0, Control/Dimming: Type: Connect, Protection: Luminaire class: Class I, IP Class: IP44, Energy and approvals: Contains light source of energy class: C, Breeam: Fulfils Hea 01 for flicker free lighting, Materials and finish: Housing: Steel, Optics: UV-stabilized polycarbonate, Mounting/Connection: Mounting: Surface, Indoor, Module: 1500, Connection: 3-pole screwless terminal block with 3x2,5mm² through wiring, Dimensions: Length (mm) L: 1500, Width (mm) W: 72, Height (mm) H: 76, Weight (kg) gross/net: 2.3 / 2, Packaging: Packaging dimensions (mm): 1523 x 76 x 88

Electrical

System wattage
31W
Voltage
220-240V
Max. luminaires per circuit breaker
B10: 26, B16: 42, C10: 43, C16: 71
Leakage current (mA)
0,4

Light technic

Type of light source
LED
Light source included
Yes
Luminous flux
4640lm
Efficacy
150 lm/W
Constant lumen output option
Yes
Colour temperature
3000K
Colour rendering (Ra)
Ra>80
MacAdams factor
SDCM: 3
Lifetime
L80/B20>100,000
Lifetime
L90>50,000
Light distribution
Direct
Optic
Opal
Visible flicker (PstLM)
<1
Stroboscopic flicker (SVM)
<0,4
Photobiological safety
RG 0

Control/Dimming

Type
Connect

Protection

Luminaire class
Class I
IP Class
IP44

Energy and approvals

Contains light source of energy class
C
Breeam
Fulfils Hea 01 for flicker free lighting

Materials and finish

Housing
Steel
Optics
UV-stabilized polycarbonate

Mounting/Connection

Mounting
Surface, Indoor
Module
1500
Connection
3-pole screwless terminal block with 3x2,5mm² through wiring

Dimensions

Length (mm) L
1500
Width (mm) W
72
Height (mm) H
76
Weight (kg) gross/net
2.3 / 2

Packaging

Packaging dimensions (mm)
1523 x 76 x 88
