Arena 600

Arena 600 3-Circuit White Medium 3690lm 3000K Ra>90 On/Off

Article code
607040
EAN
7021986070408
Back to articlelist

Overview

Efficacy
142 lm/W
Lumen
3690lm
IP Class
IP20
Colour temperature
3000K
Colour rendering (Ra)
Ra>90
Lifetime
100,000 L90/B10>
Mounting
Surface, Indoor
    5 years Warranty
  • indoor
  • dipswitch
  • ip20
  • klasse_2
  • selv
  • ce

Tools

Downloads

Specification sheet 607040 Revit file - Generic Arena 600 3-T - generic Revit file - Face Based Arena 600 3-T - face based

See more

Eulumdat file (ldt) 7021986070408_Arena 600 3-T White Medium 3690lm 3000K Ra90 OnOff Dialux file (uld) 7021986070408_Arena 600 3-T White Medium 3690lm 3000K Ra90 OnOff Relux file (rolf) 7021986070408_Arena_600_3-T_White_Medium_3690lm_3000K_Ra_90_On_Off EPD NEPD-11750-11680_Arena-600-3-T Mounting instruction Arena 600 3T_User Manual CE Declaration Arena 600 3 fase

How to specify

Text copied to clipboard

Arena 600 3-Circuit White Medium 3690lm 3000K Ra>90 On/Off, Article code: 607040, EAN: 7021986070408, IP20, Electrical: System wattage: 26W, Voltage: 220-240V, Frequency (Hz): 50/60Hz, Max. luminaires per circuit breaker: B10: 32, B16: 50, C10: 52, C16: 85, Light technic: Type of light source: LED, Luminous flux: 3690lm, Efficacy: 142 lm/W, Colour temperature: 3000K, Colour rendering (Ra): Ra>90, MacAdams factor: SDCM: 3, Lifetime: L90/B10>100,000, Light distribution: Direct, Beam angle: 60°, UGR: UGR<25, Visible flicker (PstLM): 0.02, Stroboscopic flicker (SVM): 0, Control/Dimming: Type: On/Off, Driver: 750mA, Protection: Luminaire class: Class II SELV, IP Class: IP20, Energy and approvals: Contains light source of energy class: C, Breeam: Fulfils Hea 01 for flicker free lighting, Materials and finish: Housing: Aluminium, Optics: Acrylic (PMMA), Mounting/Connection: Mounting: Surface, Indoor, Connection: ShopLine track (adapter included), Dimensions: Length (mm) L: 583, Width (mm) W: 69, Height (mm) H: 69, Weight (kg) gross/net: 1.14 / 0.91, Packaging: Packaging dimensions (mm): 600 x 85 x 120

Electrical

System wattage
26W
Voltage
220-240V
Frequency (Hz)
50/60Hz
Max. luminaires per circuit breaker
B10: 32, B16: 50, C10: 52, C16: 85

Light technic

Type of light source
LED
Luminous flux
3690lm
Efficacy
142 lm/W
Colour temperature
3000K
Colour rendering (Ra)
Ra>90
MacAdams factor
SDCM: 3
Lifetime
L90/B10>100,000
Light distribution
Direct
Beam angle
60°
UGR
UGR<25
Visible flicker (PstLM)
0.02
Stroboscopic flicker (SVM)
0

Control/Dimming

Type
On/Off
Driver
750mA

Protection

Luminaire class
Class II SELV
IP Class
IP20

Energy and approvals

Contains light source of energy class
C
Breeam
Fulfils Hea 01 for flicker free lighting

Materials and finish

Housing
Aluminium
Optics
Acrylic (PMMA)

Mounting/Connection

Mounting
Surface, Indoor
Connection
ShopLine track (adapter included)

Dimensions

Length (mm) L
583
Width (mm) W
69
Height (mm) H
69
Weight (kg) gross/net
1.14 / 0.91

Packaging

Packaging dimensions (mm)
600 x 85 x 120
