Inspire 300 3-Circuit

Inspire 300 3-Circuit White 3480lm 3000K Ra>90 On/Off

Article code
212460
EAN
7021982124600
Back to articlelist

Overview

Efficacy
102 lm/W
Lumen
3480lm
IP Class
IP20
Colour temperature
3000K
Colour rendering (Ra)
Ra>90
Lifetime
100,000 L70/B10>
Mounting
Surface, Indoor
    5 years Warranty
  • indoor
  • dipswitch
  • flickerfree
  • ip20
  • klasse_2
  • ce
  • enec

Tools

Downloads

Specification sheet 212460 Revit file - Generic Inspire 300 3-Circuit - generic Revit file - Face Based Inspire 300 3-Circuit - face based

See more

Eulumdat file (ldt) 7021982124600_Inspire 300 3-T White 3480lm 3000K Ra90 OnOff Dialux file (uld) 7021982124600_Inspire 300 3-T White 3480lm 3000K Ra90 OnOff Relux file (rolf) 7021982124600_Inspire_300_3-T_White_3480lm_3000K_Ra_90_On_Off EPD NEPD-12118-12096_Inspire-300-3-T Mounting instruction Inspire 300 3T, Dali _User Manual CE Declaration Inspire 300 3-T

How to specify

Text copied to clipboard

Inspire 300 3-Circuit White 3480lm 3000K Ra>90 On/Off, Article code: 212460, EAN: 7021982124600, IP20, Electrical: System wattage: 34W, Voltage: 220-240V, Max. luminaires per circuit breaker: B10: 32, B16: 50, C10: 52, C16: 85, Light technic: Type of light source: LED, Luminous flux: 3480lm, Efficacy: 102 lm/W, Colour temperature: 3000K, Colour rendering (Ra): Ra>90, MacAdams factor: SDCM: 3, Lifetime: L70/B10>100,000, Lifetime: L80/B10>70,000, Optic: Cubic Optic Black, UGR: UGR<22, Visible flicker (PstLM): 0,01, Stroboscopic flicker (SVM): 0,01, Photobiological safety: RG 1, Control/Dimming: Type: On/Off, Protection: Luminaire class: Class II, IP Class: IP20, Energy and approvals: Contains light source of energy class: E, Breeam: Fulfils Hea 01 for flicker free lighting, Materials and finish: Housing: Aluminium, Optics: Polycarbonat (PC), Mounting/Connection: Mounting: Surface, Indoor, Connection: ShopLine track (adapter included), Dimensions: Length (mm) L: 285, Width (mm) W: 82, Height (mm) H: 75, Weight (kg) gross/net: 0.8 / 0.7, Packaging: Packaging dimensions (mm): 290 x 87 x 80

Electrical

System wattage
34W
Voltage
220-240V
Max. luminaires per circuit breaker
B10: 32, B16: 50, C10: 52, C16: 85

Light technic

Type of light source
LED
Luminous flux
3480lm
Efficacy
102 lm/W
Colour temperature
3000K
Colour rendering (Ra)
Ra>90
MacAdams factor
SDCM: 3
Lifetime
L70/B10>100,000
Lifetime
L80/B10>70,000
Optic
Cubic Optic Black
UGR
UGR<22
Visible flicker (PstLM)
0,01
Stroboscopic flicker (SVM)
0,01
Photobiological safety
RG 1

Control/Dimming

Type
On/Off

Protection

Luminaire class
Class II
IP Class
IP20

Energy and approvals

Contains light source of energy class
E
Breeam
Fulfils Hea 01 for flicker free lighting

Materials and finish

Housing
Aluminium
Optics
Polycarbonat (PC)

Mounting/Connection

Mounting
Surface, Indoor
Connection
ShopLine track (adapter included)

Dimensions

Length (mm) L
285
Width (mm) W
82
Height (mm) H
75
Weight (kg) gross/net
0.8 / 0.7

Packaging

Packaging dimensions (mm)
290 x 87 x 80
