Inspire 300 DALI

Inspire 300 3-Circuit Black 3500lm 4000K Ra>90 DALI-2

Article code
212467
EAN
7021982124679
Back to articlelist

Overview

Efficacy
103 lm/W
Lumen
3500lm
IP Class
IP20
Colour temperature
4000K
Colour rendering (Ra)
Ra>90
Lifetime
50,000 L80/B10>
Mounting
Surface, Indoor
    5 years Warranty
  • indoor
  • el
  • dipswitch
  • flickerfree
  • ip20
  • klasse_2
  • ce
  • enec

Tools

Downloads

Specification sheet 212467 Revit file - Generic Inspire 300 DALI - generic Revit file - Face Based Inspire 300 Dali - face based

See more

Eulumdat file (ldt) 7021982124679_Inspire 300 3-T Black 3500lm 4000K Ra90 DALI-2 Dialux file (uld) 7021982124679_Inspire 300 3-T Black 3500lm 4000K Ra90 DALI-2 Relux file (rolf) 7021982124679_Inspire_300_3-T_Black_3500lm_4000K_Ra_90_DALI-2 Mounting instruction Inspire 300 3T, Dali _User Manual CE Declaration Inspire 300 DALI

How to specify

Text copied to clipboard

Inspire 300 3-Circuit Black 3500lm 4000K Ra>90 DALI-2, Article code: 212467, EAN: 7021982124679, IP20, Electrical: System wattage: 34W, Voltage: 220-240V, Max. luminaires per circuit breaker: B10: 32, B16: 50, C10: 52, C16: 85, Light technic: Type of light source: LED, Luminous flux: 3500lm, Efficacy: 103 lm/W, Colour temperature: 4000K, Colour rendering (Ra): Ra>90, MacAdams factor: SDCM: 3, Lifetime: L80/B10>50,000, Optic: Cubic Optic Black, UGR: UGR<22, Visible flicker (PstLM): 0,01, Stroboscopic flicker (SVM): 0,01, Photobiological safety: RG 1, Control/Dimming: Type: DALI-2, Protection: Luminaire class: Class II, IP Class: IP20, Energy and approvals: Contains light source of energy class: E, Breeam: Fulfils Hea 01 for flicker free lighting, Materials and finish: Housing: Aluminium, Optics: Polycarbonat (PC), Mounting/Connection: Mounting: Surface, Indoor, Connection: ShopLine DALI track (adapter included), Dimensions: Length (mm) L: 285, Width (mm) W: 82, Height (mm) H: 75, Weight (kg) gross/net: 0.83 / 0.7, Packaging: Packaging dimensions (mm): 290 x 87 x 80

Electrical

System wattage
34W
Voltage
220-240V
Max. luminaires per circuit breaker
B10: 32, B16: 50, C10: 52, C16: 85

Light technic

Type of light source
LED
Luminous flux
3500lm
Efficacy
103 lm/W
Colour temperature
4000K
Colour rendering (Ra)
Ra>90
MacAdams factor
SDCM: 3
Lifetime
L80/B10>50,000
Optic
Cubic Optic Black
UGR
UGR<22
Visible flicker (PstLM)
0,01
Stroboscopic flicker (SVM)
0,01
Photobiological safety
RG 1

Control/Dimming

Type
DALI-2

Protection

Luminaire class
Class II
IP Class
IP20

Energy and approvals

Contains light source of energy class
E
Breeam
Fulfils Hea 01 for flicker free lighting

Materials and finish

Housing
Aluminium
Optics
Polycarbonat (PC)

Mounting/Connection

Mounting
Surface, Indoor
Connection
ShopLine DALI track (adapter included)

Dimensions

Length (mm) L
285
Width (mm) W
82
Height (mm) H
75
Weight (kg) gross/net
0.83 / 0.7

Packaging

Packaging dimensions (mm)
290 x 87 x 80
