Tube Pro DALI

Tube Pro 3-Circuit Black 3830lm 4000K Ra>90 DALI-2

Article code
320857
EAN
7021983208576
Back to articlelist

Overview

Efficacy
93 lm/W
Lumen
3830lm
IP Class
IP20
Colour temperature
4000K
Colour rendering (Ra)
Ra>90
Lifetime
100,000 L90/B10>
Mounting
Surface, Indoor
    5 years Warranty
  • indoor
  • dipswitch
  • ip20
  • klasse_2
  • ce

Tools

Downloads

Specification sheet 320857 Revit file - Generic Tube Pro Dali - generic Revit file - Face Based Tube Pro 3-Circuit Dali - face based

See more

Eulumdat file (ldt) 7021983208576_Tube Pro 3-Circuit Black 3830lm 4000K Ra90 DALI Dialux file (uld) 7021983208576_Tube Pro 3-Circuit Black 3830lm 4000K Ra90 DALI Relux file (rolf) 7021983208576_Tube_Pro_3-Circuit_Black_3830lm_4000K_Ra_90_DALI EPD NEPD-7347-6736_Tube-Pro-3-T-Dali_1 Mounting instruction Tube Pro_User Manual CE Declaration Tube Pro 3-T

How to specify

Text copied to clipboard

Tube Pro 3-Circuit Black 3830lm 4000K Ra>90 DALI-2, Article code: 320857, EAN: 7021983208576, IP20, Electrical: System wattage: 41W, Voltage: 220-240V, Frequency (Hz): 50/60Hz, Max. luminaires per circuit breaker: B10: 32, B16: 50, C10: 50, C16: 85, Light technic: Type of light source: LED, Luminous flux: 3830lm, Efficacy: 93 lm/W, Colour temperature: 4000K, Colour rendering (Ra): Ra>90, MacAdams factor: SDCM: 2, Lifetime: L90/B10>100,000, Maximum ambient temperature: 35°C, Lifetime at max ambient temperature: L90/B10>50,000, Light distribution: Direct, Optic: Reflector, Beam angle: 32°, UGR: UGR<10, Visible flicker (PstLM): 0.01, Stroboscopic flicker (SVM): 0, Control/Dimming: Type: DALI-2, Driver: 1050mA, Protection: Luminaire class: Class II, IP Class: IP20, Energy and approvals: Contains light source of energy class: E, Breeam: Fulfils Hea 01 for flicker free lighting, Materials and finish: Housing: Aluminium, Optics: Glass, Mounting/Connection: Mounting: Surface, Indoor, Connection: ShopLine DALI track (adapter included), Dimensions: Length (mm) L: 278, Width (mm) W: 260, Height (mm) H: 92, Weight (kg) gross/net: 1.45 / 1.11, Packaging: Packaging dimensions (mm): 285 x 225 x 100

Electrical

System wattage
41W
Voltage
220-240V
Frequency (Hz)
50/60Hz
Max. luminaires per circuit breaker
B10: 32, B16: 50, C10: 50, C16: 85

Light technic

Type of light source
LED
Luminous flux
3830lm
Efficacy
93 lm/W
Colour temperature
4000K
Colour rendering (Ra)
Ra>90
MacAdams factor
SDCM: 2
Lifetime
L90/B10>100,000
Maximum ambient temperature
35°C
Lifetime at max ambient temperature
L90/B10>50,000
Light distribution
Direct
Optic
Reflector
Beam angle
32°
UGR
UGR<10
Visible flicker (PstLM)
0.01
Stroboscopic flicker (SVM)
0

Control/Dimming

Type
DALI-2
Driver
1050mA

Protection

Luminaire class
Class II
IP Class
IP20

Energy and approvals

Contains light source of energy class
E
Breeam
Fulfils Hea 01 for flicker free lighting

Materials and finish

Housing
Aluminium
Optics
Glass

Mounting/Connection

Mounting
Surface, Indoor
Connection
ShopLine DALI track (adapter included)

Dimensions

Length (mm) L
278
Width (mm) W
260
Height (mm) H
92
Weight (kg) gross/net
1.45 / 1.11

Packaging

Packaging dimensions (mm)
285 x 225 x 100
