Wall box

Wall box 9-24mm 4 outlets stud Grey Smart Single

Article code
79003
EAN
7021987900315
Back to articlelist

Overview

Mounting
Indoor
    5 years Warranty
  • indoor
  • ce
  • nemko
  • semko
  • fimko

Tools

Downloads

Specification sheet 79003 EPD NEPD-8257-7925_Wall-box Mounting instruction Built-in wallbox_user manual

How to specify

Text copied to clipboard

Wall box 9-24mm 4 outlets stud Grey Smart Single, Article code: 79003, EAN: 7021987900315, Materials and finish: Housing: Polypropylen (PP), Halogen free: Yes, Mounting/Connection: Mounting: Indoor, Module: 9-24mm 4 outlets stud, Dimensions: Length (mm) L: 179, Width (mm) W: 154, Height (mm) H: 64, Weight (kg) gross/net: 0.183 / 0.159, Packaging: Packaging dimensions (mm): 179 x 154 x 64, Number per pack: 48

Materials and finish

Housing
Polypropylen (PP)
Halogen free
Yes

Mounting/Connection

Mounting
Indoor
Module
9-24mm 4 outlets stud

Dimensions

Length (mm) L
179
Width (mm) W
154
Height (mm) H
64
Weight (kg) gross/net
0.183 / 0.159

Packaging

Packaging dimensions (mm)
179 x 154 x 64
Number per pack
48
