25A outlet and plug

Plug Stove 25A Grounded White

Article code
77570
EAN
7021987757018
Back to articlelist

Overview

IP Class
IP20
Mounting
Indoor
    5 years Warranty
  • indoor
  • ip20
  • nemko
  • semko
  • fimko

Tools

Downloads

Specification sheet 77570 Revit file - Generic 25A male - generic Mounting instruction Plugg Komfyr Male_User Manual

How to specify

Text copied to clipboard

Plug Stove 25A Grounded White, Article code: 77570, EAN: 7021987757018, IP20, Electrical: Voltage: 250V, Nominal current: 25A, Protection: IP Class: IP20, Energy and approvals: BVB: Yes, Materials and finish: Housing: Polycarbonat (PC), Colour: White (RAL 9003), Halogen free: Yes, Mounting/Connection: Mounting: Indoor, Dimensions: Length (mm) L: 87, Width (mm) W: 52, Height (mm) H: 32, Weight (kg) gross/net: 0.11 / 0.093, Packaging: Packaging dimensions (mm): 87 x 52 x 32, Number per pack: 6

Electrical

Voltage
250V
Nominal current
25A

Protection

IP Class
IP20

Energy and approvals

BVB
Yes

Materials and finish

Housing
Polycarbonat (PC)
Colour
White (RAL 9003)
Halogen free
Yes

Mounting/Connection

Mounting
Indoor

Dimensions

Length (mm) L
87
Width (mm) W
52
Height (mm) H
32
Weight (kg) gross/net
0.11 / 0.093

Packaging

Packaging dimensions (mm)
87 x 52 x 32
Number per pack
6
