StripLine RGBW

StripLine 10m 790lm/m RGBW (3000K) Ra>90

Article code
391479
EAN
7021983914798
Back to articlelist

Overview

Wattage
15W/m
Efficacy
53 lm/W
Lumen
790lm/m
IP Class
IP54
Colour temperature
RGBW (3000K)
Colour rendering (Ra)
Ra>90
Lifetime
50,000 L70/B50>
Mounting
Surface, Indoor / Outdoor
    5 years corrosion warranty 5 years Warranty
  • indoor
  • outdoor
  • 24v
  • ip54
  • klasse_3
  • rgbw
  • ce

Tools

Downloads

Specification sheet 391479 Eulumdat file (ldt) 7021983914798_StripLine RGBW 110lmm RED Eulumdat file (ldt) 7021983914798_StripLine RGBW 280lmm 3000K Ra90

See more

Eulumdat file (ldt) 7021983914798_StripLine RGBW 320lmm GREEN Eulumdat file (ldt) 7021983914798_StripLine RGBW 80lmm BLUE Dialux file (uld) 7021983914798_StripLine RGBW 110lmm RED Dialux file (uld) 7021983914798_StripLine RGBW 280lmm 3000K Ra90 Dialux file (uld) 7021983914798_StripLine RGBW 320lmm GREEN Dialux file (uld) 7021983914798_StripLine RGBW 80lmm BLUE Relux file (rolf) 7021983914798_StripLine_RGBW_110lmm_RED Relux file (rolf) 7021983914798_StripLine_RGBW_280lmm_3000K_Ra90 Relux file (rolf) 7021983914798_StripLine_RGBW_320lmm_GREEN Relux file (rolf) 7021983914798_StripLine_RGBW_80lmm_BLUE Mounting instruction Stripline RGBW_User Manual CE Declaration Stripline RGBW

How to specify

Text copied to clipboard

StripLine 10m 790lm/m RGBW (3000K) Ra>90, Article code: 391479, EAN: 7021983914798, IP54, Electrical: Wattage: 15W/m, System wattage: 15W, Voltage: 24V, Light technic: Type of light source: LED, Luminous flux: 790lm/m, Efficacy: 53 lm/W, Colour temperature: RGBW (3000K), Colour rendering (Ra): Ra>90, MacAdams factor: SDCM: 3, Lifetime: L70/B50>50,000, Light distribution: Direct, Beam angle: 120°, UGR: UGR<25, Visible flicker (PstLM): 0.01, Stroboscopic flicker (SVM): 0, Protection: Luminaire class: Class III, IP Class: IP54, Energy and approvals: Contains light source of energy class: G, Materials and finish: Optics: Polyuretan (PU), Mounting/Connection: Mounting: Surface, Indoor / Outdoor, Module: 10m, Cable: Cable 2x2m, Dimensions: Length (mm) L: 10000, Width (mm) W: 12, Height (mm) H: 3.2, Weight (kg) gross/net: 0.932 / 0.802, Packaging: Packaging dimensions (mm): 233 x 225 x 45

Electrical

Wattage
15W/m
System wattage
15W
Voltage
24V

Light technic

Type of light source
LED
Luminous flux
790lm/m
Efficacy
53 lm/W
Colour temperature
RGBW (3000K)
Colour rendering (Ra)
Ra>90
MacAdams factor
SDCM: 3
Lifetime
L70/B50>50,000
Light distribution
Direct
Beam angle
120°
UGR
UGR<25
Visible flicker (PstLM)
0.01
Stroboscopic flicker (SVM)
0

Protection

Luminaire class
Class III
IP Class
IP54

Energy and approvals

Contains light source of energy class
G

Materials and finish

Optics
Polyuretan (PU)

Mounting/Connection

Mounting
Surface, Indoor / Outdoor
Module
10m
Cable
Cable 2x2m

Dimensions

Length (mm) L
10000
Width (mm) W
12
Height (mm) H
3.2
Weight (kg) gross/net
0.932 / 0.802

Packaging

Packaging dimensions (mm)
233 x 225 x 45
