Fenes Maxi

Fenes Maxi Lens 2 6830lm 4000K Ra>70 On/Off

Article code
212789
EAN
7021982127892
Back to articlelist

Overview

Efficacy
159 lm/W
Lumen
6830lm
IP Class
IP66
Colour temperature
4000K
Colour rendering (Ra)
Ra>70
Lifetime
100,000 L80/B20>
Mounting
Pole - Side Top (Ø42-48/Ø60), Outdoor
    5 years corrosion warranty 5 years Warranty
  • outdoor
  • flickerfree
  • ik08
  • ip66
  • klasse_2
  • ce

Tools

Downloads

Specification sheet 212789 Revit file - Generic Fenes Maxi - generic Revit file - Face Based Fenes Maxi - face based

See more

Eulumdat file (ldt) 7021982127892_Fenes Maxi Lens 2 6830lm 4000K Ra70 OnOff Dialux file (uld) 7021982127892_Fenes Maxi Lens 2 6830lm 4000K Ra70 OnOff Relux file (rolf) 7021982127892_Fenes_Maxi_Lens_2_6830lm_4000K_Ra_70_On_Off EPD NEPD-8555-8229_Fenes-Maxi-Lense-2 Mounting instruction Fenes Maxi_User Manual CE Declaration Fenes Maxi

How to specify

Text copied to clipboard

Fenes Maxi Lens 2 6830lm 4000K Ra>70 On/Off, Article code: 212789, EAN: 7021982127892, IP66, IK08, Electrical: System wattage: 43W, Frequency (Hz): 50/60Hz, Max. luminaires per circuit breaker: B10: 6, B16: 10, C10: 10, C16: 16, Light technic: Type of light source: LED, Luminous flux: 6830lm, Efficacy: 159 lm/W, Colour temperature: 4000K, Colour rendering (Ra): Ra>70, MacAdams factor: SDCM: 3, Lifetime: L80/B20>100,000, Light distribution: Direct, Optic: PMMA, Polymethylmethacrylat, ULOR (<1%): Yes, up to 25° tilt angle, Control/Dimming: Type: On/Off, Protection: Luminaire class: Class II, IK Class: IK08, IP Class: IP66, Surge protection: 6/10 kV, Materials and finish: Housing: Aluminium, Colour: Grey RAL 7042, Optics: Tempered glass, Mounting/Connection: Mounting: Pole - Side Top (Ø42-48/Ø60), Outdoor, Module: Lens 2, Cable: Cable 2x1.0mm² 8m, H05RN-F, Dimensions: Length (mm) L: 432, Width (mm) W: 188, Height (mm) H: 145, Weight (kg) gross/net: 5.112 / 4.478, Packaging: Packaging dimensions (mm): 530 x 190 x 105

Electrical

System wattage
43W
Frequency (Hz)
50/60Hz
Max. luminaires per circuit breaker
B10: 6, B16: 10, C10: 10, C16: 16

Light technic

Type of light source
LED
Luminous flux
6830lm
Efficacy
159 lm/W
Colour temperature
4000K
Colour rendering (Ra)
Ra>70
MacAdams factor
SDCM: 3
Lifetime
L80/B20>100,000
Light distribution
Direct
Optic
PMMA, Polymethylmethacrylat
ULOR (<1%)
Yes, up to 25° tilt angle

Control/Dimming

Type
On/Off

Protection

Luminaire class
Class II
IK Class
IK08
IP Class
IP66
Surge protection
6/10 kV

Materials and finish

Housing
Aluminium
Colour
Grey RAL 7042
Optics
Tempered glass

Mounting/Connection

Mounting
Pole - Side Top (Ø42-48/Ø60), Outdoor
Module
Lens 2
Cable
Cable 2x1.0mm² 8m, H05RN-F

Dimensions

Length (mm) L
432
Width (mm) W
188
Height (mm) H
145
Weight (kg) gross/net
5.112 / 4.478

Packaging

Packaging dimensions (mm)
530 x 190 x 105
