Herning Wall

Herning Wall Grey Midi 1060/1140/1770/1920lm 3000/4000K Ra>80 Trailing edge

Article code
623963
EAN
7021986239638
Back to articlelist

Overview

Wattage
13W/25W
Efficacy
82/88/71/77lm/W
Lumen
1060/1140/1770/1920lm
IP Class
IP65
Colour temperature
3000/4000K
Colour rendering (Ra)
Ra>80
Lifetime
50,000 L80/B20>
Mounting
Wall, Indoor / Outdoor
    5 years corrosion warranty 5 years Warranty
  • indoor
  • outdoor
  • dipswitch
  • flickerfree
  • cctsw
  • ik06
  • ip65
  • klasse_2
  • ce

Tools

Downloads

Specification sheet 623963 Revit file - Generic Herning Wall Midi - generic Revit file - Face Based Herning Wall Midi - face based

See more

Eulumdat file (ldt) 7021986239638_Herning Wall Midi Grey 1060lm 3000K Ra80 Trailing edge dimming Eulumdat file (ldt) 7021986239638_Herning Wall Midi Grey 1140lm 4000K Ra80 Trailing edge dimming Eulumdat file (ldt) 7021986239638_Herning Wall Midi Grey 1770lm 3000K Ra80 Trailing edge dimming Eulumdat file (ldt) 7021986239638_Herning Wall Midi Grey 1920lm 4000K Ra80 Trailing edge dimming Dialux file (uld) 7021986239638_Herning Wall Midi Grey 1060lm 3000K Ra80 Trailing edge dimming Dialux file (uld) 7021986239638_Herning Wall Midi Grey 1140lm 4000K Ra80 Trailing edge dimming Dialux file (uld) 7021986239638_Herning Wall Midi Grey 1770lm 3000K Ra80 Trailing edge dimming Dialux file (uld) 7021986239638_Herning Wall Midi Grey 1920lm 4000K Ra80 Trailing edge dimming Relux file (rolf) 7021986239638_Herning_Wall_Midi_Grey_1060lm_3000K_Ra80_Trailing_edge_dimming Relux file (rolf) 7021986239638_Herning_Wall_Midi_Grey_1140lm_4000K_Ra80_Trailing_edge_dimming Relux file (rolf) 7021986239638_Herning_Wall_Midi_Grey_1770lm_3000K_Ra80_Trailing_edge_dimming Relux file (rolf) 7021986239638_Herning_Wall_Midi_Grey_1920lm_4000K_Ra80_Trailing_edge_dimming EPD NEPD-8333-8002_Herning-Wall-Midi Mounting instruction Herning_User Manual CE Declaration Herning Wall

How to specify

Text copied to clipboard

Herning Wall Grey Midi 1060/1140/1770/1920lm 3000/4000K Ra>80 Trailing edge, Article code: 623963, EAN: 7021986239638, IP65, IK06, Electrical: Wattage: 13W/25W, Voltage: 220-240V, Frequency (Hz): 50/60Hz, Max. luminaires per circuit breaker: B10: 23, B16: 36, C10: 37, C16: 60, Light technic: Type of light source: LED, Luminous flux: 1060/1140/1770/1920lm, Efficacy: 82/88/71/77lm/W, Colour temperature: 3000/4000K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L80/B20>50,000, Light distribution: Direct, Optic: Glass, UGR: UGR<25, Photobiological safety: RG 1, ULOR (<1%): Yes, Control/Dimming: Type: Trailing edge, Protection: Luminaire class: Class II, IK Class: IK06, IP Class: IP65, Energy and approvals: Contains light source of energy class: E, Materials and finish: Housing: Aluminium, Colour: Grey RAL 7042, Mounting/Connection: Mounting: Wall, Indoor / Outdoor, Connection: Screwless terminal block, Wind projected area: 0,0435m², Dimensions: Length (mm) L: 402, Width (mm) W: 240, Height (mm) H: 222, Weight (kg) gross/net: 3.354 / 2.62, Packaging: Packaging dimensions (mm): 420 x 250 x 240

Electrical

Wattage
13W/25W
Voltage
220-240V
Frequency (Hz)
50/60Hz
Max. luminaires per circuit breaker
B10: 23, B16: 36, C10: 37, C16: 60

Light technic

Type of light source
LED
Luminous flux
1060/1140/1770/1920lm
Efficacy
82/88/71/77lm/W
Colour temperature
3000/4000K
Colour rendering (Ra)
Ra>80
MacAdams factor
SDCM: 3
Lifetime
L80/B20>50,000
Light distribution
Direct
Optic
Glass
UGR
UGR<25
Photobiological safety
RG 1
ULOR (<1%)
Yes

Control/Dimming

Type
Trailing edge

Protection

Luminaire class
Class II
IK Class
IK06
IP Class
IP65

Energy and approvals

Contains light source of energy class
E

Materials and finish

Housing
Aluminium
Colour
Grey RAL 7042

Mounting/Connection

Mounting
Wall, Indoor / Outdoor
Connection
Screwless terminal block
Wind projected area
0,0435m²

Dimensions

Length (mm) L
402
Width (mm) W
240
Height (mm) H
222
Weight (kg) gross/net
3.354 / 2.62

Packaging

Packaging dimensions (mm)
420 x 250 x 240
