Arco Air

Decorative LED lamp for wall and garden. Made of powder-coated corrosion-proof aluminium. Installed with dimmable, replaceable GU10 LED bulb (included) that illuminates a top reflector, thus giving soft light with a pleasant effect. Impact-resistant with IK08 and phenolic screw to prohibit access to the light source.

Article list

Arco Air

Trailing edge Outdoor Direct/Indirect Pole, wall, bollard or earthing rod, Surface Class I IK08 IP54 Beam angle: 360°

Filters

Colour temperature

Lumen

SDCM

Colour rendering (Ra)

						Others	Tools
623620	2700K	6W	75lm	2	Ra>90	13 lm/W, Ø160 x H963, Screwless terminal block, L70/B50> 50,000	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
623621	2700K	6W	75lm	2	Ra>90	13 lm/W, Ø160 x H400, R, Screwless terminal block, L70/B50> 50,000	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
623622	2700K	6W	75lm	2	Ra>90	13 lm/W, W160 x H356 x D219, Screwless terminal block, L70/B50> 50,000	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
623623	3000K	6.2W	100lm	4	Ra>80	16 lm/W, Ø160 x H963, Screwless terminal block, L70/B50> 25,000	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
623624	3000K	6.2W	100lm	4	Ra>80	16 lm/W, Ø160 x H400, Screwless terminal block, L70/B50> 25,000	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
623625	3000K	6.2W	100lm	4	Ra>80	16 lm/W, W160 x H356 x D219, Screwless terminal block, L70/B50> 25,000	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)

Sorry, we couldn’t find what you are looking for.

						Others	Tools
623620	2700K	6W	75lm	2	Ra>90	13 lm/W, Ø160 x H963, Screwless terminal block, L70/B50> 50,000	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
623621	2700K	6W	75lm	2	Ra>90	13 lm/W, Ø160 x H400, R, Screwless terminal block, L70/B50> 50,000	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
623622	2700K	6W	75lm	2	Ra>90	13 lm/W, W160 x H356 x D219, Screwless terminal block, L70/B50> 50,000	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
623623	3000K	6.2W	100lm	4	Ra>80	16 lm/W, Ø160 x H963, Screwless terminal block, L70/B50> 25,000	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
623624	3000K	6.2W	100lm	4	Ra>80	16 lm/W, Ø160 x H400, Screwless terminal block, L70/B50> 25,000	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
623625	3000K	6.2W	100lm	4	Ra>80	16 lm/W, W160 x H356 x D219, Screwless terminal block, L70/B50> 25,000	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)

Sorry, we couldn’t find what you are looking for.

Accessories

Image	Article code	Description	Dimensions	Tools
	600581	Arco Air Anchoring set Steel	Ø148 x H245	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
