Duett
Duett White E27 350lm 2700K Ra>80 Trailing edge
- Article code
- 611393
- EAN
- 7021986113938
Overview
- Efficacy
- 35 lm/W
- Lumen
- 350lm
- IP Class
- IP65
- Colour temperature
- 2700K
- Colour rendering (Ra)
- Ra>80
- Lifetime
- 50,000 L70/B50>
- Mounting
- Surface, Outdoor
Tools
Downloads
Specification sheet
611393
pdf
(Opens in new tab)
Mounting instruction
Duett Mounting instruction
pdf
(Opens in new tab)
CE Declaration
Duett
pdf
(Opens in new tab)
Relux file (rolf)
7021986113938_Duett_White_E27_350lm_2700K_Ra_80_Trailing_edge_dimming
rolf
Eulumdat file (ldt)
7021986113938_Duett E27 White 10W LED 2700K Ra80-43960
ldt
Dialux file (uld)
7021986113938_Duett E27 White 10W LED 2700K Ra80
uld
Revit file - Generic
Duett - Generic
rfa
Revit file - Face Based
Duett - face based
rfa
Electrical
- System wattage
- 10W
- Voltage
- 220-240V
- Max. luminaires per circuit breaker
- B10: 33, B16: 52, C10: 40, C16: 64
Light technic
- Type of light source
- LED
- Socket
- E27
- Light source included
- Yes
- Luminous flux
- 350lm
- Efficacy
- 35 lm/W
- Colour temperature
- 2700K
- Colour rendering (Ra)
- Ra>80
- MacAdams factor
- SDCM: 6
- Lifetime
- L70/B50>50,000
- Light distribution
- Direct
- Optic
- Opal
- Beam angle
- 100°
- Photobiological safety
- RG 0
- ULOR (<1%)
- Yes
Control/Dimming
- Type
- Trailing edge
Protection
- Luminaire class
- Class I
- IK Class
- IK10
- IP Class
- IP65
Energy and approvals
- Contains light source of energy class
- F
- Breeam
- Fulfils Hea 01 for flicker free lighting
- BVB
- Yes
Materials and finish
- Housing
- Aluminium
- Colour
- White (RAL 9003)
- Optics
- UV-stabilized polycarbonate
Mounting/Connection
- Mounting
- Surface, Outdoor
- Connection
- Screwless terminal block
Dimensions
- Width (mm) W
- 271
- Height (mm) H
- 142
- Depth (D)
- 148
- Weight (kg) gross/net
- 2.04 / 1.618
Packaging
- Packaging dimensions (mm)
- 280 x 155 x 155
