Junistar Eco IsoSafe

Junistar ECO Isosafe Black DimToWarm 470lm 2000-2800K Ra>95 Trailing edge

Article code
905217
EAN
7021989052173
Back to articlelist

Overview

Wattage
6W
Efficacy
67 lm/W
Lumen
470lm
IP Class
IP44
Colour temperature
2000-2800K
Colour rendering (Ra)
Ra>95
Lifetime
50,000 L90/B10>
Mounting
Recessed, Indoor
    5 years Warranty
  • indoor
  • isosafe
  • fire
  • sound
  • dimtowarm
  • ip44
  • tilt30
  • klasse_2
  • selv
  • ce

Tools

Downloads

Specification sheet 905217 Mounting instruction Junistar Eco IsoSafe DTW_User manual Eulumdat file (ldt) 7021989052173_Junistar Eco IsoSafe DimToWarm Black 6W LED 2000-2800K Ra95-41073

See more

Dialux file (uld) 7021989052173_Junistar Eco IsoSafe DimToWarm Black 6W LED 2000-2800K Ra95 Relux file (rolf) 7021989052173_Junistar_ECO_Isosafe_Black_DimToWarm_470lm_2000-2800K_Ra_95_Trailing_edge_dimming EPD NEPD-6441-5706_Junistar-Eco-IsoSafe Revit file - Generic Junistar Eco IsoSafe - Generic Revit file - Ceiling Based Junistar ECO Isosafe - ceiling based Sound insulation Sound Insulation Firerated Firerated CE Declaration Junistar Eco Isosafe

How to specify

Text copied to clipboard

Junistar ECO Isosafe Black DimToWarm 470lm 2000-2800K Ra>95 Trailing edge, Article code: 905217, EAN: 7021989052173, IP44, Electrical: Wattage: 6W, System wattage: 7W, Voltage: 220-240V, Max. luminaires per circuit breaker: B10: 105, B16: 168, C10: 105, C16: 168, Light technic: Type of light source: LED, Luminous flux: 470lm, Efficacy: 67 lm/W, Colour temperature: 2000-2800K, Colour rendering (Ra): Ra>95, MacAdams factor: SDCM: 3, Lifetime: L90/B10>50,000, Light distribution: Direct, Optic: Reflector, Beam angle: 42°, UGR: UGR<22, Control/Dimming: Type: Trailing edge, Protection: Luminaire class: Class II SELV, IP Class: IP44, Energy and approvals: Contains light source of energy class: F, Breeam: Fulfils Hea 01 for flicker free lighting, Passed 60-minute fire resistance test in accordance with EN 1365-2: Yes, Sound insulation test passed according to EN ISO 10140-2:2021 and 10140-3:2021 part E: Yes, Materials and finish: Housing: Aluminium, Colour: Black (RAL 9004), Optics: Tempered glass, Mounting/Connection: Mounting: Recessed, Indoor, Connection: Screwless terminal block, Dimensions: Height (mm) H: 40, Diameter (mm) D: 90, Cut-out (mm): 83, Weight (kg) gross/net: 0.361 / 0.361, Packaging: Packaging dimensions (mm): 122 x 121 x 95, Number per pack: 8

Electrical

Wattage
6W
System wattage
7W
Voltage
220-240V
Max. luminaires per circuit breaker
B10: 105, B16: 168, C10: 105, C16: 168

Light technic

Type of light source
LED
Luminous flux
470lm
Efficacy
67 lm/W
Colour temperature
2000-2800K
Colour rendering (Ra)
Ra>95
MacAdams factor
SDCM: 3
Lifetime
L90/B10>50,000
Light distribution
Direct
Optic
Reflector
Beam angle
42°
UGR
UGR<22

Control/Dimming

Type
Trailing edge

Protection

Luminaire class
Class II SELV
IP Class
IP44

Energy and approvals

Contains light source of energy class
F
Breeam
Fulfils Hea 01 for flicker free lighting
Passed 60-minute fire resistance test in accordance with EN 1365-2
Yes
Sound insulation test passed according to EN ISO 10140-2:2021 and 10140-3:2021 part E
Yes

Materials and finish

Housing
Aluminium
Colour
Black (RAL 9004)
Optics
Tempered glass

Mounting/Connection

Mounting
Recessed, Indoor
Connection
Screwless terminal block

Dimensions

Height (mm) H
40
Diameter (mm) D
90
Cut-out (mm)
83
Weight (kg) gross/net
0.361 / 0.361

Packaging

Packaging dimensions (mm)
122 x 121 x 95
Number per pack
8
