Arena Sport

How to specify

Arena Sport 1200 296mm White Wide 22370lm 4000K Ra>80 DALI-2, Article code: 8246094403, EAN: 5703821177337, IP23, IK10, Electrical: System wattage: 144W, Voltage: 220-240V, Max. luminaires per circuit breaker: B10: 3, B16: 5, C10: 5, C16: 8, Leakage current (mA): 0.18, Light technic: Type of light source: LED, Luminous flux: 22370lm, Efficacy: 155 lm/W, Colour temperature: 4000K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L80/B20>100,000, Lifetime: L90/B10>70,000, Minimum ambient temperature: -25°C, Light distribution: Direct, Optic: Lens Wide, Beam angle: Wide, UGR: UGR<25, Visible flicker (PstLM): 0.03, Photobiological safety: RG 1, Control/Dimming: Type: DALI-2, Protection: Luminaire class: Class I, IK Class: IK10, IP Class: IP23, Energy and approvals: Contains light source of energy class: C, Breeam: Fulfils Hea 01 for flicker free lighting, BVB: Yes, Sunda Hus: B, Materials and finish: Housing: Sheet steel, Colour: White (RAL 9010, 20% gloss), Optics: Acrylic (PMMA), Mounting/Connection: Mounting: Surface, Indoor, Module: 1200 296mm, Connection: 7-pole screwless terminal block with 5x2,5mm2 (+DALI) through wiring, Dimensions: Length (mm) L: 1263, Width (mm) W: 296, Height (mm) H: 80, Weight (kg) gross/net: 10.7 / 10.5, Packaging: Packaging dimensions (mm): 1270 x 314 x 85
