Rax Soft 150 Connect Wireless

A version of Rax Soft, which is combined with a wide range of SG Connect Driver Kit Wireless to provide the desired amount of light.

The lighting control is easy to configure using the SG Connect Commissioning App, and the luminaire can be used with a wireless sensor or as part of a larger system, along with other SG Connect luminaires with integrated sensors, which can easily be enlarged or reconfigured as needed.

The light is turned on and off after a defined period of time, contributing to energy saving. Rax Soft Connect is installed easily with springs that fit ceiling panels with a thickness of 1–50 mm.

Article list

Rax Soft 150 Connect Wireless

Indoor Direct Recessed SDCM: 2 Class II SELV IK08 IP44/IP20 Ra>80 Beam angle: 68° L90/B10> 100,000

Filters

Colour temperature

				Others	Tools
	212770	3000K	Connect Wireless	Ø166 x H83, Quick connector	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
	212771	4000K	Connect Wireless	Ø166 x H83, Quick connector	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)

Sorry, we couldn’t find what you are looking for.

Drivers

				Others	Tools
820503	13W	Connect/ Linect	Wireless	L157 x W45 x H30, 3 pol Linect / screwless terminal block	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
820504	18W	Connect/ Linect	Wireless	L157 x W45 x H30, 3 pol Linect / screwless terminal block	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
820506	26W	Connect/ Linect	Wireless	L157 x W45 x H30, 3 pol Linect / screwless terminal block	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)

Sorry, we couldn’t find what you are looking for.

				Others	Tools
	212770	3000K	Connect Wireless	Ø166 x H83, Quick connector	Select driver
	212771	4000K	Connect Wireless	Ø166 x H83, Quick connector	Select driver

Sorry, we couldn’t find what you are looking for.

					Others	Tools
212770+820503	3000K	13W	1600lm	Connect Wireless	123 lm/W, Ø166 x H83, 3 pol Linect / screwless terminal block	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
212771+820503	4000K	13W	1650lm	Connect Wireless	127 lm/W, Ø166 x H83, 3 pol Linect / screwless terminal block	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
212771+820504	4000K	18W	2220lm	Connect Wireless	123 lm/W, Ø166 x H83, 3 pol Linect / screwless terminal block	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
212771+820506	4000K	26W	3070lm	Connect Wireless	118 lm/W, Ø166 x H83, 3 pol Linect / screwless terminal block	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)

Sorry, we couldn’t find what you are looking for.

Accessories

Article code	Description	Dimensions	Tools
212617	Rax 150 Black Rehabring Ø155-200mm Sheet steel	Ø220 x H16	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
212621	Rax 150 Black Glass clear IP44	Ø168 x H12	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
212623	Rax 150 Black Glass frosted IP44	Ø168 x H12	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
212620	Rax 150 White Glass clear IP44	Ø168 x H12	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
212622	Rax 150 White Glass frosted IP44	Ø168 x H12	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8249044683	Rax 150 White Rehabring Ø155-200mm Sheet steel	Ø220 x H16	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
900109	Reliefplate Weight distribution panel Plastic	L400 x W400 x H1	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8249042216	Rax 150 Mounting plate Sheet steel	L585 x W260 x H15	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
