Tube Eco DALI

Tube Eco 3-Circuit White 2410lm 4000K Ra>90 DALI-2

Article code
312451
EAN
7021983124517
Back to articlelist

Overview

Efficacy
93 lm/W
Lumen
2410lm
IP Class
IP20
Colour temperature
4000K
Colour rendering (Ra)
Ra>90
Lifetime
100,000 L90/B10>
Mounting
Surface, Indoor
    5 years Warranty
  • indoor
  • el
  • flickerfree
  • ip20
  • klasse_1
  • ce

Tools

Downloads

Specification sheet 312451 Revit file - Generic Tube ECO Dali - generic Revit file - Face Based Tube ECO Dali - face based

See more

Eulumdat file (ldt) 7021983124517_Tube Eco 3-Circuit White 1960lm 4000K Ra90 DALI Honeycomb Eulumdat file (ldt) 7021983124517_Tube Eco 3-Circuit White 2410lm 4000K Ra90 DALI Dialux file (uld) 7021983124517_Tube Eco 3-Circuit White 1960lm 4000K Ra90 DALI Honeycomb Dialux file (uld) 7021983124517_Tube Eco 3-Circuit White 2410lm 4000K Ra90 DALI Relux file (rolf) 7021983124517_Tube_Eco_3-Circuit_White_2410lm_4000K_Ra_90_DALI_Honeycomb Relux file (rolf) 7021983124517_Tube_Eco_3-Circuit_White_2410lm_4000K_Ra_90_DALI EPD NEPD-8554-8230_Tube-Eco-3-T-Dali Mounting instruction Tube Eco DALI_User Manual CE Declaration Tube Eco DALI

How to specify

Text copied to clipboard

Tube Eco 3-Circuit White 2410lm 4000K Ra>90 DALI-2, Article code: 312451, EAN: 7021983124517, IP20, Electrical: System wattage: 26W, Voltage: 220-240V, Frequency (Hz): 50/60Hz, Max. luminaires per circuit breaker: B10: 31, B16: 50, C10: 52, C16: 85, Light technic: Type of light source: LED, Luminous flux: 2410lm, Efficacy: 93 lm/W, Colour temperature: 4000K, Colour rendering (Ra): Ra>90, MacAdams factor: SDCM: 3, Lifetime: L90/B10>100,000, Maximum ambient temperature: 35°C, Lifetime at max ambient temperature: L90/B10>50,000, Light distribution: Direct, Optic: Reflector, Beam angle: 32°, Control/Dimming: Type: DALI-2, Protection: Luminaire class: Class I, IP Class: IP20, Energy and approvals: Contains light source of energy class: E, Breeam: Fulfils Hea 01 for flicker free lighting, Materials and finish: Housing: Aluminium, Colour: Matte white (RAL 9003), Optics: Glass, Mounting/Connection: Mounting: Surface, Indoor, Connection: ShopLine DALI track (adapter included), Dimensions: Height (mm) H: 220, Diameter (mm) D: 92, Weight (kg) gross/net: 1.35 / 1.16, Packaging: Packaging dimensions (mm): 306 x 142 x 105

Electrical

System wattage
26W
Voltage
220-240V
Frequency (Hz)
50/60Hz
Max. luminaires per circuit breaker
B10: 31, B16: 50, C10: 52, C16: 85

Light technic

Type of light source
LED
Luminous flux
2410lm
Efficacy
93 lm/W
Colour temperature
4000K
Colour rendering (Ra)
Ra>90
MacAdams factor
SDCM: 3
Lifetime
L90/B10>100,000
Maximum ambient temperature
35°C
Lifetime at max ambient temperature
L90/B10>50,000
Light distribution
Direct
Optic
Reflector
Beam angle
32°

Control/Dimming

Type
DALI-2

Protection

Luminaire class
Class I
IP Class
IP20

Energy and approvals

Contains light source of energy class
E
Breeam
Fulfils Hea 01 for flicker free lighting

Materials and finish

Housing
Aluminium
Colour
Matte white (RAL 9003)
Optics
Glass

Mounting/Connection

Mounting
Surface, Indoor
Connection
ShopLine DALI track (adapter included)

Dimensions

Height (mm) H
220
Diameter (mm) D
92
Weight (kg) gross/net
1.35 / 1.16

Packaging

Packaging dimensions (mm)
306 x 142 x 105
