Area 66

How to specify

Area 66 Grey 4500lm 4000K Ra>80 On/Off, Article code: 120001, EAN: 7021981200015, IP66, IK10, Electrical: System wattage: 36W, Voltage: 220-240V, Max. luminaires per circuit breaker: B10: 12, B16: 19, C10: 20, C16: 32, Leakage current (mA): 0.27, Light technic: Type of light source: LED, Luminous flux: 4500lm, Efficacy: 125 lm/W, Colour temperature: 4000K, Colour rendering (Ra): Ra>80, MacAdams factor: SDCM: 3, Lifetime: L80/B10>100,000, Lifetime: L90/B50>50,000, Minimum ambient temperature: -25°C, Maximum ambient temperature: 45°C, Lifetime at max ambient temperature: L80/B20>50,000, Light distribution: Direct, Optic: Opal, Beam angle: 100°, UGR: UGR<28, Control/Dimming: Type: On/Off, Protection: Luminaire class: Class I, IK Class: IK10, IP Class: IP66, Fire protection class: 850°C - 30s, Energy and approvals: Contains light source of energy class: D, Breeam: Fulfils Hea 01 for flicker free lighting, BVB: Yes, Sunda Hus: C+, Food Safety approved (IFS and HACCP): Yes, Materials and finish: Housing: UV-stabilized polycarbonate, Colour: Grey, Optics: UV-stabilized polycarbonate, Mounting/Connection: Mounting: Surface, Indoor, Connection: 5-pole screwless terminal block with 5x2,5mm2 through wiring, Dimensions: Length (mm) L: 1174, Width (mm) W: 92, Height (mm) H: 70, Weight (kg) gross/net: 2.832 / 2.36, Packaging: Packaging dimensions (mm): 1230 x 110 x 80
