Zip Pro 3-Circuit

Zip Pro 3-Circuit Silver 40° 2840lm 4000K Ra>90 On/Off

Article code
3497
EAN
7021980034970
Back to articlelist

Overview

Efficacy
79 lm/W
Lumen
2840lm
IP Class
IP20
Colour temperature
4000K
Colour rendering (Ra)
Ra>90
Lifetime
100,000 L80/B20>
Mounting
Surface, Indoor
    5 years Warranty
  • indoor
  • dipswitch
  • ip20
  • klasse_1
  • ce

Tools

Downloads

Specification sheet 3497 Mounting instruction Zip Pro Mounting instructions CE Declaration Zip Pro Relux file (rolf) 7021980034970_Zip_Pro_3-Circuit_Silver_40D_2840lm_4000K_Ra_90_On_Off Eulumdat file (ldt) 7021980034970_Zip Pro 3 Circuit 40D Silver 42W LED 4000K Ra90-37988 Dialux file (uld) 7021980034970_Zip Pro 3 Circuit 40D Silver 42W LED 4000K Ra90

How to specify

Text copied to clipboard

Zip Pro 3-Circuit Silver 40° 2840lm 4000K Ra>90 On/Off, Article code: 3497, EAN: 7021980034970, IP20, Electrical: System wattage: 36W, Voltage: 220-240V, Light technic: Type of light source: LED, Luminous flux: 2840lm, Efficacy: 79 lm/W, Colour temperature: 4000K, Colour rendering (Ra): Ra>90, MacAdams factor: SDCM: 2, Lifetime: L80/B20>100,000, Lifetime: L90/B10>50,000, Light distribution: Direct, Optic: Reflector, Beam angle: 40°, UGR: UGR<22, Control/Dimming: Type: On/Off, Protection: Luminaire class: Class I, IP Class: IP20, Energy and approvals: Contains light source of energy class: E, Breeam: Fulfils Hea 01 for flicker free lighting, Materials and finish: Housing: Aluminium, Colour: Silver, Optics: Tempered glass, Mounting/Connection: Mounting: Surface, Indoor, Connection: ShopLine track (adapter included), Dimensions: Length (mm) L: 218, Width (mm) W: 100, Height (mm) H: 219, Weight (kg) gross/net: 1.56 / 1.388, Packaging: Packaging dimensions (mm): 110 x 250 x 255

Electrical

System wattage
36W
Voltage
220-240V

Light technic

Type of light source
LED
Luminous flux
2840lm
Efficacy
79 lm/W
Colour temperature
4000K
Colour rendering (Ra)
Ra>90
MacAdams factor
SDCM: 2
Lifetime
L80/B20>100,000
Lifetime
L90/B10>50,000
Light distribution
Direct
Optic
Reflector
Beam angle
40°
UGR
UGR<22

Control/Dimming

Type
On/Off

Protection

Luminaire class
Class I
IP Class
IP20

Energy and approvals

Contains light source of energy class
E
Breeam
Fulfils Hea 01 for flicker free lighting

Materials and finish

Housing
Aluminium
Colour
Silver
Optics
Tempered glass

Mounting/Connection

Mounting
Surface, Indoor
Connection
ShopLine track (adapter included)

Dimensions

Length (mm) L
218
Width (mm) W
100
Height (mm) H
219
Weight (kg) gross/net
1.56 / 1.388

Packaging

Packaging dimensions (mm)
110 x 250 x 255
