Lineal Surface

Lineal Surface is a modular system solution for surface mounting, with a perfect, well thought-out design for continuous light in illuminated lines.The efficient lighting solution optimises visual comfort and light quality, and makes Lineal Surface ideal for many applications such as offices, corridors and foyers or as decorative lighting.For each continuous line, you need one or more straight lines and/or corners, a start kit and a front cover.Lineal Surface can be combined with Lineal Cubic Surface/Suspended, enabling creative lighting designs.

Article list

Lineal Surface

Indoor Direct SDCM: 3 Class I IK08 IP20 Ra>80 L80/B10> 100,000

Filters

Color

Module

Colour temperature

System wattage

Lumen

Filters

						Others	Tools
8246094720	Corner	3000K	17W	1740lm	DALI-2 / Push Dim	102 lm/W, L642 x W42 x H70 x D571, 5-pole Winsta mini with 5x2,5mm2 through wiring, 1x2m wire kit w/ceiling bracket, Suspended	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095800	840	3000K	13W	1280lm	DALI-2 / Push Dim	98 lm/W, L841 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095826	1120	3000K	17W	1740lm	DALI-2 / Push Dim	102 lm/W, L1121 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095839	1400	3000K	21W	2160lm	DALI-2 / Push Dim	103 lm/W, L1401 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246094746	Corner	3000K	17W	1870lm	DALI-2 / Push Dim	110 lm/W, L642 x W42 x H70 x D571, 5-pole Winsta mini with 5x2,5mm2 through wiring, 1x2m wire kit w/ceiling bracket, Suspended	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095855	840	3000K	13W	1380lm	DALI-2 / Push Dim	106 lm/W, L841 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095871	1120	3000K	17W	1870lm	DALI-2 / Push Dim	110 lm/W, L1121 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095897	1400	3000K	21W	2320lm	DALI-2 / Push Dim	110 lm/W, L1401 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246094733	Corner	4000K	17W	1830lm	DALI-2 / Push Dim	108 lm/W, L642 x W42 x H70 x D571, 5-pole Winsta mini with 5x2,5mm2 through wiring, 1x2m wire kit w/ceiling bracket, Suspended	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095062	1120	4000K	17W	1830lm	DALI-2 / Push Dim	108 lm/W, L1121 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095813	840	4000K	13W	1350lm	DALI-2 / Push Dim	104 lm/W, L841 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095842	1400	4000K	21W	2270lm	DALI-2 / Push Dim	108 lm/W, L1401 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246094759	Corner	4000K	17W	1970lm	DALI-2 / Push Dim	116 lm/W, L642 x W42 x H70 x D571, 5-pole Winsta mini with 5x2,5mm2 through wiring, 1x2m wire kit w/ceiling bracket, Suspended	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095868	840	4000K	13W	1450lm	DALI-2 / Push Dim	112 lm/W, L841 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095884	1120	4000K	17W	1970lm	DALI-2 / Push Dim	116 lm/W, L1121 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095907	1400	4000K	21W	2440lm	DALI-2 / Push Dim	116 lm/W, L1401 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095910	Start kit					L140 x W140 x H55, Cable 5x0,75mm² 2,5m Halogen free	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8246095923	Start kit					L140 x W140 x H55, Cable 5x0,75mm² 2,5m Halogen free	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)

Sorry, we couldn’t find what you are looking for.

						Others	Tools
8246094720	Corner	3000K	17W	1740lm	DALI-2 / Push Dim	102 lm/W, L642 x W42 x H70 x D571, 5-pole Winsta mini with 5x2,5mm2 through wiring, 1x2m wire kit w/ceiling bracket, Suspended	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095800	840	3000K	13W	1280lm	DALI-2 / Push Dim	98 lm/W, L841 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095826	1120	3000K	17W	1740lm	DALI-2 / Push Dim	102 lm/W, L1121 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095839	1400	3000K	21W	2160lm	DALI-2 / Push Dim	103 lm/W, L1401 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246094746	Corner	3000K	17W	1870lm	DALI-2 / Push Dim	110 lm/W, L642 x W42 x H70 x D571, 5-pole Winsta mini with 5x2,5mm2 through wiring, 1x2m wire kit w/ceiling bracket, Suspended	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095855	840	3000K	13W	1380lm	DALI-2 / Push Dim	106 lm/W, L841 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095871	1120	3000K	17W	1870lm	DALI-2 / Push Dim	110 lm/W, L1121 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095897	1400	3000K	21W	2320lm	DALI-2 / Push Dim	110 lm/W, L1401 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246094733	Corner	4000K	17W	1830lm	DALI-2 / Push Dim	108 lm/W, L642 x W42 x H70 x D571, 5-pole Winsta mini with 5x2,5mm2 through wiring, 1x2m wire kit w/ceiling bracket, Suspended	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095062	1120	4000K	17W	1830lm	DALI-2 / Push Dim	108 lm/W, L1121 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095813	840	4000K	13W	1350lm	DALI-2 / Push Dim	104 lm/W, L841 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095842	1400	4000K	21W	2270lm	DALI-2 / Push Dim	108 lm/W, L1401 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246094759	Corner	4000K	17W	1970lm	DALI-2 / Push Dim	116 lm/W, L642 x W42 x H70 x D571, 5-pole Winsta mini with 5x2,5mm2 through wiring, 1x2m wire kit w/ceiling bracket, Suspended	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095868	840	4000K	13W	1450lm	DALI-2 / Push Dim	112 lm/W, L841 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095884	1120	4000K	17W	1970lm	DALI-2 / Push Dim	116 lm/W, L1121 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095907	1400	4000K	21W	2440lm	DALI-2 / Push Dim	116 lm/W, L1401 x W42 x H70, 5-pole Winsta mini with 5x2,5mm2 through wiring, Surface	Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab) EPD (PDF) (Opens in new tab)
8246095910	Start kit					L140 x W140 x H55, Cable 5x0,75mm² 2,5m Halogen free	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8246095923	Start kit					L140 x W140 x H55, Cable 5x0,75mm² 2,5m Halogen free	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)

Sorry, we couldn’t find what you are looking for.

Accessories

Article code	Description	Dimensions	Tools
8246095965	Lineal 1120 Black Blind profile DALI-2 / Push Dim	L1121 x W42 x H70	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
212198	Black T-carrier ceiling bracket Aluminium	L30 x W20 x H5	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8241000346	Lineal Wall Start kit Black	L265 x W265 x H70	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8241000348	Lineal Wall Extension kit Black	L115 x W93 x H64	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8241000354	Lineal T-ceiling Start kit Black	L285 x W240 x H28	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8241000356	Lineal T-ceiling Extension kit Black	L120 x W94 x H65	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8249045080	Lineal 2240 Black Blind profile Front	L2240 x W38 x H4	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8246095952	Lineal 1120 White Blind profile DALI-2 / Push Dim	L1121 x W42 x H70	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8241000344	Lineal Wall Start kit White	L265 x W265 x H70	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8241000347	Lineal Wall Extension kit White	L115 x W93 x H64	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8241000353	Lineal T-ceiling Start kit White	L285 x W240 x H28	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8241000355	Lineal T-ceiling Extension kit White	L120 x W94 x H65	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8249045077	Lineal 2240 White Blind profile Front	L2240 x W38 x H4	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8249044968	Lineal 2800 Front	L2800 x W38 x H4	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8249044971	Lineal 5600 Front	L5600 x W38 x H4	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8249044984	Lineal 8400 Front	L8400 x W38 x H4	Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
8249045116	Lineal Wire kit 1 x 2m		Info Mounting instruction (PDF) (Opens in new tab) Info Mounting instruction (PDF) (Opens in new tab)
